Enterprise Capacity 2.5 HDD SATA Product Manual Standard Self-Encrypting models models ST2000NX0243 ST2000NX0283 4096 Native ST1000NX0303 ST1000NX0343 ST2000NX0253 ST2000NX0303 Emulation ST1000NX0313 ST1000NX0353 ST2000NX0403 Native ST1000NX0423 100715314, Rev. D July 2015...
Page 2
Publication number: 100715314, Rev. D July 2015 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. PowerChoice and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.
For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-returns/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: https://direct.seagate.com/portal/system For Seagate reseller portal, visit: http://spp.seagate.com Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
The Self-Encrypting Drive models indicated on the cover of this product manual have provisions for “Security of Data at Rest” based on the standards defined by Note the Trusted Computing Group (see www.trustedcomputinggroup.org). Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The specification can be downloaded from www.serialata.org. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Startup current (typical) 12V (peak) 1.85A (optional configuration through Smart Command Transport) 5V ±5% Voltage tolerance (including noise) 12V ±5% 5° to 55°C (operating/tested) Ambient temperature –40° to 70°C (nonoperating) Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Page 10
*One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Maximum (peak) DC 0.60 0.33 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Page 13
Maximum (peak) DC 0.60 0.30 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
If the standby timer reaches zero before any drive activity is required, the drive makes a transition to Standby mode. In both Idle and Standby mode, the drive accepts all commands and returns to Active mode when disk access is necessary. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
• Saved enabled state, and timer value • Current enabled state, and timer value S.M.A.R.T. Read Data Reports • Attribute 192 - Emergency Retract Count • Attribute 193 - Load/Unload Cycle Count Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Page 18
Disable EPC Feature Set PowerChoice Supported Extended Power Condition Identifiers Power Condition Identifiers Power Condition Name Standby_z 01 - 80 Reserved Idle_a Idle_b Idle_c 84 - FE Reserved All EPC Power Conditions Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp.
3.0 bels (max) 3.4 bels (max) *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA- 74 standards.
EN 55024. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. The drive is designed for operation inside a properly designed enclosure, with properly shielded I/O cable (if necessary) and terminators on all unused I/O ports.
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%.
Product warranty Beginning on the date of shipment to the customer and continuing for the period specified in the purchase contract, Seagate warrants that each product (including components and subassemblies) that fails to function properly under normal use due to defect in materials or workmanship or due to nonconformance to the applicable specifications will be repaired or replaced, at Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated...
Image is for reference only, may not represent actual drive Note Each cable is keyed to ensure correct orientation. Enterprise Capacity 2.5 HDD v3 SATA drives support latching SATA connectors. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
• Do not cover breather hole on top cover. Breather Hole Do Not Cover Figure 5. Breather hole location - top cover Image is for reference only, may not represent actual drive Note Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
1TB models 190 g 0.419 lb These dimensions conform to the Small Form Factor Standard Note documented in SFF-8201 and SFF-8223, found at www.sffcommittee.org. Figure 6. Mounting configuration dimensions Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate’s SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two ATA commands: •...
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1.
The drive shall not support the OVERWRITE EXT and BLOCK ERASE EXT sub-commands. Support of the SANITIZE FREEZE LOCK EXT command shall be determined on a customer-specific basis. OEM drives shall support the command. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
12V power, pre-charge, 2nd mate 12V power 12V power * Pins P1, P2 and P3 are tied together. † Host commanded disable via pin P3 is NOT supported by Enterprise Capacity 2.5 HDD Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
137GB). Drives with capacities over 137GB will have 0FFFFFFFh in this field and the actual number of user-addressable LBAs specified in words 100-103. This is required for drives that support the 48-bit addressing feature. Retired 0000 Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Page 36
The mandatory value of the world wide name (WWN) for the drive. Each drive will have a unique NOTE: This field is valid if word 84, bit 8 is set to 1 indicating 64-bit WWN support. value. 112–118 ATA-reserved 0000 Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Page 37
Shall be cleared to 0. Word 88 Ultra DMA mode 0 is supported. Ultra DMA mode 1 is supported. Ultra DMA mode 2 is supported. Ultra DMA mode 3 is supported. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate Enterprise Capacity 2.5 HDD v3 SATA Product Manual, Rev. D...
Page 40
Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100715314, Rev.
