ICP OLR105A12D Installation Instructions Manual page 44

ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21A
21B
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
B50036 C
PARTS LIST
Model : NOUF105A12D
PART #
B30756-01 Complete heat exchanger (combustion chamber included)
B30465-01 Top heat exchanger
B30517 Gasket, heat exchanger
B30518 Combustion chamber (item 3 included)
B30757 Bottom heat exchanger
F07O001 Hexagonal flange nut 3/8-16NC brass
F06F015 Washer 1 7/16 zinc
B30431 Divider panel
B30430 Floor
B30426 Baffle
B30457 Rear panel assembly
B30419 Rear panel insulation
B30458-01 Right side panel assembly
B30418 Right side panel insulation
B30760-01 Front panel assembly (labels included, without logo)
B30761 Front panel insulation
B30455 Blower door assembly (labels included)
Z99F050 Door handle
B30458-02 Left side panel assembly
B30418 Left side panel insulation
B30459 5" breech plate (chimney application)
B30515 3" breech plate (direct vent application)
B30415-02 Gasket, heat exchanger
F07O001 Hexagonal flange nut 3/8-16NC brass
F07F024 Hexagonal nut 3/8-16NC brass
Z99F050 Door handle
L05F011 Terminal strip, 6 positions
B30808-01 Electrical box cover
L01H009 Relay SPDT 24VAC
L01F009 Transformer 120/24 VAC / 40 VA
R02I005 Fan Limit Control
L07F003 Rocker switch SPST
B30826 Electrical box (box only)
B30433 Blower side rails
B03720-04 Blower 100-10T (housing and wheel)
L06H004 1/2 HP direct drive motor (without legs)
B30096 Blower electrical kit
B01024 Capacitor holder
L01I002 Capacitor 7.5 MF
B01888 Motor mount assembly (Band, legs, nut & bolts included)
B01291-01 Seal strip 1 1/2" x 13 1/8"
B01405-03 Blower assembly (items 34, 35, 37, 38, 39 & 40 included)
B30513 Blower slide support
Z99F061 Sight glass
L07F016 Rocker switch SPST (main power)
A00336 Terminal strip, 6 positions
B30534 Gasket, burner
B40293 Front door, vestibule
B30725 Right panel, vestibule
B30726 Left panel, vestibule
B30723 Top panel, vestibule
B30724 Bottom panel, vestibule
Z06F001 Draft regulator
N01J040 Beckett burner AFG-F0
Z06G001 Blocked vent shut off BVSO
B03118-01 External electrical kit BVSO
