ICP OLR105A12D Installation Instructions Manual page 32

ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28A
28B
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
B50031 C
PARTS LIST
Model: OLR105A12D
PART#
B30756-02 Complete heat exchanger
B30465-02 Top heat exchanger
B30518 Combustion chamber
B30517 Gasket, heat exchanger
B30757 Bottom heat exchanger
F07O001 Hexagonal flange nut 3/8-16NC brass
F06F015 Washer 1 7/16 zinc
B30488 Divider panel
B30478 Plenum divider
B30472 Floor
B30509-02 Left side panel assembly
B30493-04 Left side panel insulation
B30833-01 Top rear panel
B30512 Blower door assembly (labels included)
B30507 Air filter drawer
Z04F004 Paper filter 20 x 20 x 1
B30509-05 Right side panel assembly
B30493-03 Right side panel insulation
B30832-01
Right filter support
B30479-02 Left filter support
J06L002 Seal strip 1/4" x 1/8" x 25'
B30768-01 Front panel assembly (labels included, without logo)
B30762 Front panel insulation
F06F005 Washer 3/8" AA zinc
F07F024 Hexagonal nut 3/8-16NC brass
Z99F061 Sight glass
F07O001 Hexagonal flange nut 3/8-16NC brass
B30459 5" breech plate (chimney application)
B30515 3" breech plate (direct vent application)
B30415-02 Gasket, heat exchanger
B30808-01 Electrical box cover
B30828 Electrical box (box only)
L07F003 Rocker switch SPST (constant blower operation)
R02I005 Fan Limit Control
L01F009 Transformer 120/24 VAC / 40 VA
L01H009 Relay SPDT 24VAC
L05F011 Terminal strip, 6 positions
B03720-04 Blower 100-10T (housing and wheel)
B01024 Capacitor holder
L01I001 Capacitor 5 MF
B30057 Blower electrical kit
F11F007 Cable tie
B30473 Blower support bracket
B01890-01 Motor assembly 1/3 HP (motor, bellyband and legs included)
B01888 Bellyband assembly (band, legs, nut & bolts included)
B01405-03 Blower assembly (items 37, 38, 39 & 43 included)
Z01F006 Rubber grommet
B01291-01 Seal strip 1 1/2" x 13 1/8"
B01025-99 Tab
B30415-01 Gasket, access cover
B30487 Flange plate
F07O001 Hexagonal flange nut 3/8-16NC brass
B30486 Access cover
L07F016 Rocker switch SPST (main power)
A00336 Terminal strip, 6 positions
B30481 Blower baffle
B30415-02 Gasket, access cover
B30534 Gasket, burner
B30415-02 Gasket, access cover
B30533 Gasket, sealing plate
Z06G001 Blocked vent shut off BVSO
B03118-01 External electrical kit
DESCRIPTION
33
