B50032 D

PARTS LIST

Model : OLR160B20C
PART #
B30786-02 Complete heat exchanger (combustion chamber included)
B30596 Top heat exchanger
B30531 Combustion chamber (item 7 included)
F07O001 Hexagonal flange nut 3/8-16NC brass
F06F015 Washer 1 7/16 zinc
B30787 Bottom heat exchanger
B30532 Gasket, heat exchanger
B30534 Gasket, heat exchanger
B30415-02 Gasket, heat exchanger
B30665 Front baffle
B30664 Rear baffle
B30666 Divider panel
B30669 Plenum divider
B30481 Blower baffle
B30663 Floor
B30680-02 Left side panel assembly
B30686-02 Left side panel insulation
B30668-02 Left bottom filter support
B30667 Left top filter support
B10256-99 Tab
B01291-02 Gasket, seal strip
B30683 Blower door assembly (labels included)
B30678 Air filter drawer
B30836-01 Top rear panel
B30589-01 Gasket, breech plate
B30646 6" breech plate (chimney application)
B30647 4" breech plate (direct vent application)
F07O001 Hexagonal flange nut 3/8-16NC brass
J06L002 Seal strip 1/2" x 1/8" x 25'
B30680-05 Right side panel assembly
B30686-01 Right side panel insulation
B30668-01 Right bottom filter support
B30835 Right top filter support
B30782-01 Front panel assembly (labels included, without logo)
B30780 Front panel insulation
Z99F061 Sight glass
F06F005 Washer 3/8" AA zinc
F07F024 Hexagonal nut 3/8-16NC brass
Z04F007 Paper filter 16 x 24 x 1
B30676 Flange plate
F07O001 Hexagonal flange nut 3/8-16NC brass
B30486 Access cover
B30808-01 Electrical box cover
L05F011 Terminal strip, 6 positions
L07F016 Rocker switch SPST (main power)
L07F003 Rocker switch SPST (constant blower operation)
B30828 Electrical box (box only)
R02I005 Fan Limit Control 8"
L01F009 Transformer 120/24 VAC / 40 VA
A00336 Terminal strip, 6 positions
L01H009 Relay SPDT 24VAC
Z01F006 Rubber grommet.
B01756 Blower support bracket
B30530-01 Blower electrical kit
L04I010 Strain release bushing
B01024 Capacitor holder
L01I005 15 MF capacitor
B03720-05 Blower 120-10T (housing and wheel)
B01406-06 Blower assembly (items 55, 56, 57, 59 and 60 included)
B01889 Motor mount assembly (band, legs, nut & bolts included)
L06I004 3/4 HP direct drive motor (without legs)
Z06G001 Blocked vent shut off BVSO
B03118-01 External electrical kit BVSO
