ICP OLR105A12D Installation Instructions Manual page 38

ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34A
34B
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
B50034 D
PARTS LIST
Model : OUF160B18C
PART #
B30786-01 Complet heat exchanger (combustion chamber included)
B30597 Top heat exchanger
B30531 Combustion chamber (item 5 included)
F07O001 Hexagonal flange nut 3/8-16NC brass
B30532 Gasket, heat exchanger
B30787 Bottom heat exchanger
B30619 Rear baffle
B30618 Front baffle
B30639 Top baffle
B30627 Divider panel
B30625 Blower slide support
B30628 Floor
Z04F011 Paper filter 24 x 24 x 1
B30656 Filter rack assembly (supplied as an option)
B30653-02 Left side panel assembly
B30658 Left side panel insulation
B30652 Rear panel assembly
B30659 Rear panel insulation
F07O001 Hexagonal flange nut 3/8-16NC brass
B30487 Breech plate
B30415-01 Gasket, access cover
B30415-02 Gasket, heat exchanger
B30653-01 Right side panel assembly
B30658 Right side panel insulation
F06F015 Washer 1 7/16 zinc
B30534 Gasket, burner
B30589-01 Gasket, breech plate
B30781-01 Front panel assembly (labels included)
B30779 Front panel insulation
B30651 Blower door assembly (labels included, without logo)
Z99F050 Door handle
F06F005 Washer 3/8" AA zinc
F07F024 Hexagonal nut 3/8-16NC brass
B30646 6" breech plate (chimney application)
B30647 4" breech plate (direct vent application)
F07O001 Hexagonal flange nut 3/8-16NC brass
B30826 Electrical box (box only)
L01H009 Relay SPDT 24VAC
L01F009 Transformer 120/24 VAC / 40 VA
R02I005 Fan Limit Control
L07F003 Rocker switch SPST (constant blower operation)
B30808-01 Electrical box cover
Z99F061 Sight glass
L06K004 Motor 1 HP DD (without legs)
B01889 Motor mount assembly (band, legs, nut & bolts included)
L05F011 Terminal strip, 6 positions
B30530 Blower electrical kit
B03720-05 Blower 120-10T (housing and wheel)
B01291-01 Seal strip
B30626 Blower side rails
B02167-01 Blower assembly (items 43, 44, 47, 51 and 52 included)
B01024 Capacitor holder
L01I003 Capacitor 10 MF
L07F016 Rocker switch SPST (main power)
A00336 Terminal strip, 6 positions
B30533 Gasket, sealing plate
Z06G001 Blocked vent shut off BVSO
B03118-01 External Electrical kit for BVSO
DESCRIPTION
39
