anti tailgate
Turned OFF - Close timer will close the gate. If an in-ground safety or exit loop
gets activated during the close cycle, gate will REVERSE to the open position.
Turned ON - (In-ground loops required) Gate will close after all the in-ground
loops have been cleared no matter how long the close timer is set for. If an
in-ground safety loop gets activated during the close cycle, gate will REVERSE
to the open position.
Single p ass anti-tailgate
Turned ON - (In-ground loops required) Gate will close after all the in-ground
loops have been cleared no matter how long the close timer is set for. When an
in-ground safety loop gets activated during the close cycle, gate will PAUSE and
NOT reopen. When loop is cleared, gate will continue to close preventing
UNAUTHORIZED entry.
1
UNAUTHORIZED Vehicle Approaches
NO VALID open command is given.
Vehicle is attempting to activate safety loop
before the gate's close cycle is complete,
expecting gate to reopen.
2
UNAUTHORIZED Vehicle
NO VALID open command.
Safety Loop gets activated and PAUSES the closing gate.
Gate will NOT reopen. Vehicle MUST back up for loop to
clear, then gate continues to close. NO unauthorized entry.
matrix 1
- Gate Pauses - - Gate Pauses -
MATRIX 1
BATTERY
BACK-UP MODE
LEAVE
CLOSED
MADE in USA LEAVE
OPEN
AUTOMATIC OPEN/CLOSE CONTROLS
ANTI
TAILGATE
EXIT
ON OFF
ANTI
CENTER
TAILGATE
SAFETY SAFETY
MIN MAX
OFF
CLOSE TIMER
ON OFF
PARTIAL
OPEN
ID
PLUG
POSITION
RECORDER
12VDC
GND OBD PORT
LED stays ON BLACK BOX
24VDC
GND
when Anti Tailgate
is ON
MATRIX 1 Back
OFF
ON
ON
Mode 0
OFF
ON
Mode 1
OFF
Gate in Motion Alarms
ON
Mode 0
OFF
ON
Mode 1
OFF
WWW.Max.US.com
AUTHORIZED Vehicle
VALID open command was given.
When last Safety Loop is cleared, gate will close.
NOTE: If a VALID open command is received at this
point, gate will stop and reopen.
PRIMARY
GATE
MAGLOCK
DELAY
OPEN OPEN
OPEN MAG
1 TIME LEFT RIGHT
OFF 1.5Sec 2Sec LOCK
COM
NC
Tamper NO
GATE
EXIT CENTER SAFETY
COM
TAMPER
GND
Tamper IN
PHOTOCELL
UL EDGE 1
ENTRAP EDGE 2
ID PLUG
MOTOR MOTION
ERROR
UL ALARM 12V
ALARM RET
RESET
OPEN STOP CLOSE
GND
MAX REVERSE SENSITIVITY
GATE SPEED
MOTOR OVERLOAD
OPEN
GATE
MIN
NO LIMIT SWITCH /
STATUS COM
CLAMP SLIPPING
MAX
CLOSE
LIMIT BATTERY
SWITCH
IN USE
ON-LINE
MOTOR
ON-LINE POWER
PRIMARY SEC
GATE GATE
OFF

Single Pass Anti-Tailgate

ON
When turned "ON"; After a vehicle clears the Safety Loop, a closing
gate will PAUSE if a second vehicle attempts to tailgate. The second
vehicle must then back off the safety loop for the gate to continue
closing. A new radio signal will open the gate.
Motion Alarm sounds before gate moves and continues until gate stops
Motion Alarms OFF
Beeper Alert sounds in Battery Back-Up Mode while gate is in motion
Beeper Alert OFF
OFF ON
Radio Safety Pause
When turned "ON" a moving gate will pause if a radio input signal is
received. The next radio signal causes the gate to continue in the
original direction.
MADE IN USA
