Cleaning 19°, 26°, 36°, and 50° glass lenses
Caution: Change lenses if they become visibly damaged
to the extent that their effectiveness is impaired, for
example, by cracks or deep scratches.
1.
Remove the beam focus knob at the bottom of the
barrel. Remove the lens tube from the barrel.
2.
Dampen a clean, lint-free cloth with vinegar or
household ammonia. You may also use water, but it
will leave spots which you may remove by polishing
the lens gently with a clean, dry cloth.
Warning: Never use glass and window cleaner or
any abrasive material to clean the lens. Glass and
window cleaners will stain the lens surface. Abrasive
materials (such as steel wool) will damage the lens.
3.
Starting from the center, gently wipe the lens.
4.
Slide the lens tube back into the barrel with the color
frame retaining clip on top. Replace beam focus
knob.
Cleaning the reflector
Remove the lens tube. Remove dust from the reflector
with a blast of oil-free air, or wipe with a clean, lint-free
cloth. If this is not sufficient, follow the instructions
below. You will need a Phillips screwdriver to complete
this procedure.
Warning: Unplug the fixture before attempting to clean
reflector.
Warning: Do not use glass and window cleaners on the
reflector. Chemicals in these cleaners will stain the
reflector.
1.
Unscrew and remove the barrel rotation knob located
at the bottom of the barrel. Use a Phillips screwdriver
to undo retainer bolt located at the top of the
reflector housing.
2.
Grasp the barrel and rotate it 45° in either direction.
Carefully remove the barrel from the reflector
housing and set it aside.
3.
Dampen a clean, lint-free cloth with alcohol or
distilled water. (Alcohol is recommended.)
4.
Gently wipe the reflector.
5.
Insert the barrel into the reflector housing with the
pattern slot on top. (Line up the triangles on both
parts.)
6.
Pressing in gently, rotate the barrel 45° clockwise
until it settles into position. Rotate the barrel counter-
clockwise 45°. The barrel should be firmly attached
and the triangles should line up again.
7.
Replace the barrel rotation knob and tighten the bolt.
Electronic Theatre Controls
North America 3030 Laura Lane
Europe 5 Victoria Industrial Estate
Asia Room 605-606
World Wide Web: http://www.etcconnect.com
Copyright 1997 Specifications subject to change. Source Four is protected by US patent numbers 5,345,371, 5,446,637, 5,268,613 and 5,544,029. Patents Pending. 7060M1001. Revised 11/97.
Middleton, Wisconsin 53562
•
Victoria Road
London W3 6UU
•
•
Tower III
Enterprise Square
9 Sheung Yuet Road
•
•
•
Email: mail@etcconnect.com
•
Cleaning 5° and 10° polymer lenses
Remove dust with a blast of oil-free air. If this is not
sufficient, follow the instructions below. You will need a
Phillips screwdriver.
Caution: Handle polymer lenses by their edges only.
Never rub anything dry on a polymer lens. Do not use
glass and window cleaners on the lens.
Caution: Change lenses if they become visibly damaged
or deformed to the extent that their effectiveness is
impaired, for example, by cracks or deep scratches.
1.
Remove the beam focus knob. Gently pull the lens
tube out of the barrel.
2.
Use a Phillips screwdriver to remove the brackets
that hold the lens in. Remove the lens from the lens
tube.
3.
Dip lens in clean alcohol/water mixture (10% alcohol).
4.
Use a moistened nylon bristle brush to wash the
smooth side in a straight motion.
5.
Use the same moistened brush to clean the ridged
side, following the ridges, without hand pressure.
6.
Dip lens in clean alcohol/water mixture (ten percent
alcohol).
7.
Use air gun to dry the smooth surface.
8.
Use air gun to dry the ridged surface. Use air stream
to move liquid away from you. Continue to remove as
much liquid as possible.
9.
Inspect the lens for dirt. Repeat the entire process, as
necessary.
10. Set the lens back in the lens tube with the ridged side
facing the front of the tube. Replace the brackets.
11. Slide the lens tube back into the barrel with gel frame
retainer on top. Replace beam focus knob.
HPL lamps
L
a
m
p
c
o
d
e
H
P
L
3
7
5
1 /
1
H
P
L
3
7
5
1 /
1
H
P
L
5
5
0
7 /
7
H
P
L
5
5
0
7 /
7
H
P
L
5
7
5
1 /
1
H
P
L
5
7
5
1 /
1
H
P
L
5
7
5
1 /
2
H
P
L
5
7
5
2 /
3
H
P
L
5
7
5
2 /
4
Important: Do not use lamps other than the HPL in
Source Four fixtures.
