Blizzard Lighting Blockhead II User Manual page 18

DMX Values In-Depth (29-Channel Mode, continued)
27 000 <--> 255
28
000 <--> 049
050 <--> 074
075 <--> 099
100 <--> 124
125 <--> 149
150 <--> 199
200 <--> 255
29
000 <--> 250
251 <--> 255
DMX Values In-Depth (19-Channel Mode)
19CH Channel Value
1 000 <--> 255
2
000 <--> 055
056 <--> 155
156 <--> 255
3 000 <--> 255
4
000 <--> 055
056 <--> 155
156 <--> 255
5 000 <--> 255
6 000 <--> 255
7
000 <--> 003
004 <--> 095
096 <--> 176
177 <--> 255
8 000 <--> 255
9 000 <--> 255
10 000 <--> 255
11 000 <--> 255
12
000 <--> 007
008 <--> 015
016 <--> 023
024 <--> 031
032 <--> 039
040 <--> 047
048 <--> 055
056 <--> 063
064 <--> 071
072 <--> 079
080 <--> 087
088 <--> 095
096 <--> 103
104 <--> 111
112 <--> 119
120 <--> 127
128 <--> 135
136 <--> 143
144 <--> 151
152 <--> 159
160 <--> 167
168 <--> 175
176 <--> 183
184 <--> 191
192 <--> 199
200 <--> 207
208 <--> 215
216 <--> 223
BlockHead™ II User Manual Rev. A
Effect Speed (fast <--> slow)
Macro Function Control
No Function
Numbers, Symbols, and Patterns (control with channel 22)
Letters (control with channel 23)
Static Pattern Effects (control with channel 24)
Dynamic Pattern Effects (control with channel 26)
Auto Mode
Sound Active Mode
Reset
No Function
Resets fixture motors after 3 seconds
What it does
Pan (0-540 degree)
Infinite Pan
No function
Continuous Rotating CW
Continuous Rotating CCW
Tilt (0-540 degree)
Infinite Tilt
No function
Continuous Rotating CW
Continuous Rotating CCW
Pan, Tilt Speed (Slow <--> Fast)
Dimmer (0% <--> 100%)
Strobe (slow <--> fast)
No Function
Strobe Speed
Random Strobe
Thunder Strobe
Red Intensity (0% <--> 100%)
Green Intensity (0% <--> 100%)
Blue Intensity (0% <--> 100%)
White Intensity (0% <--> 100%)
Numbers, Symbols, and Punctuations
0
1
2
3
4
5
6
7
8
9
+
~
×
÷
/
<
>
Pattern 1
Pattern 2
Pattern 3
Pattern 4
Pattern 5
Pattern 6
Pattern 7
Pattern 8
Pattern 9
.
=
Page 18
(c) 2015 Blizzard Lighting, LLC
