SL PAR 155 ZOOM RGBW LED Luminaire
LCD Display / Menu System
Home (menu settings)
LCD Display
LEFT Arrow Button
NOTE: Menu rotates with orientation of
luminaire and menu buttons are always in
the same position (with rotation of menu)
Note: For Menu operation and programming details, refer to
14.
Sh wline
Edit a Preset
RIGHT Arrow Button
Figure 3: LCD Display & Menu System
SL PAR 155 ZOOM
To rotate menu 180 degrees from current orientation,
press and hold the two center buttons for 2 seconds.
"LCD Display and Menu System Operation" on page
SL PAR 155 ZOOM RGBW LED Luminaire Components
Installation & User's Manual
Edit a Chase
DMX512 Addressing
Return to Main Screen /
Return Up One Level
DOWN Arrow Button
UP Arrow Button
CHECK MARK (Accept) Button
7
