Summary of Contents for Showline SL PAR 155Zoom

  • Page 2: Showline Offices

    Showline office. El contenido de este manual es solamente para información y está sujeto a cambios sin previo aviso. Showline no asume responsabilidad por errores o omisiones que puedan aparecer. Cualquier comentario, sugerencia o corrección con respecto a este manual, favor de dirijirlo a la oficina de Showline más cercana.

  • Page 3: Important Information

    Showline Limited Two-Year Warranty Showline offers a two-year limited warranty of its luminaires against defects in materials or workmanship from the date of delivery. A copy of Showline two-year limited warranty containing specific terms and conditions can be obtained by contacting your local Showline office.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Showline Offices............................. Inside Front Cover IMPORTANT INFORMATION Warnings and Notices................................. 1 Additional Resources for DMX512............................ 1 Showline Limited Two-Year Warranty ..........................1 TABLE OF CONTENTS PREFACE About this Manual ..................................4 Included Items..................................... 4 Accessories ....................................5 SL PAR 155 ZOOM RGBW LED Luminaire Power Input Cables (North American Models Only) .......
  • Page 5 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual RDM PARAMETER IDS SL PAR 155 ZOOM RGBW LED Luminaire RDM Parameter IDs ..................37 CLEANING AND CARE Special Cleaning and Care Instructions ............................ 40 Front Lens Cleaning.................................. 40 Service and Maintenance ................................

  • Page 6: Preface

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual PREFACE 1. About this Manual The document provides installation and operation instructions for the following products: • SL PAR 155 ZOOM RGBW LED Luminaire Please read all instructions before installing or using this product. Retain this manual for future reference. Additional product information and descriptions may be found on the product specification sheet.

  • Page 7: Accessories

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual 3. Accessories Contact your Authorized Showline Dealer for price and availability of all accessories for SL PAR 155 ZOOM RGBW LED Luminaires. SL PAR 155 ZOOM RGBW LED Luminaire Power Input Cables (North American Models...

  • Page 8: Sl Par 155 Zoom Rgbw Led Luminaire Overview

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual SL PAR 155 ZOOM RGBW LED LUMINAIRE OVERVIEW 1. SL PAR 155 ZOOM RGBW LED Luminaire Components Common Luminaire Components Front of Unit Rear of Unit Yoke Assembly AC Input DMX512 / RDM Input LCD Display / Menu System DMX512 / RDM Output...

  • Page 9: Lcd Display / Menu System

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual LCD Display / Menu System Edit a Preset Edit a Chase Home (menu settings) DMX512 Addressing Return to Main Screen / Return Up One Level SL PAR 155 ZOOM LCD Display DOWN Arrow Button LEFT Arrow Button...

  • Page 10: Installation And Set Up

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual INSTALLATION AND SET UP 1. Power Requirements The SL PAR 155 ZOOM RGBW LED Luminaires operate on AC input voltages from 100 to 240 VAC. WARNING! SL PAR 155 ZOOM RGBW LED Luminaires do not contain an ON/OFF switch. Always disconnect power input cable to completely remove power from the luminaire when not in use.

  • Page 11: Connecting Sl Par 155 Zoom Rgbw Led Luminaires To Ac Power

    Figure 4: SL PAR 155 ZOOM RGBW LED Luminaire AC Input & Output Connections CAUTION: In the event the AC input cable of this luminaire is damaged, it must be replaced, by the user, with an approved cable through an Authorized Showline Dealer or Service Center. Sh wline...

  • Page 12: Connecting To The Dmx512 Network

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual 3. Connecting to the DMX512 Network Basic DMX512 installation consists of connecting multiple SL PAR 155 ZOOM RGBW LED Luminaires together (up to 32 luminaires) in "daisy-chain" fashion. A cable runs from the control console (or DMX512 control source) to the DMX connector on the first SL PAR 155 ZOOM RGBW LED Luminaire.

  • Page 13: Mounting Luminaire

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual 4. Mounting Luminaire Truss / Hanging Applications The SL PAR 155 ZOOM RGBW LED Luminaire is provided with the ability to hang via truss hooks, clamps, etc. (sold separately). Simply attach hook, clamp, etc. to the SL PAR 155 ZOOM RGBW LED Luminaire enclosure assembly in the provided M13 holes.

  • Page 14: Floor Mounting

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Truss Hook or Clamp (sold separately) SAFETY CABLE: Is sold separately and recommended for all hanging installation and may be required by national and local codes. Use safety cable anchor point for this fixture.

  • Page 15: Setting / Adjusting Zoom

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Setting / Adjusting Zoom The SL PAR 155 ZOOM RGBW LED Luminaire has a user-adjustable, manual zoom. The zoom is easily changed by loosening both the zoom adjustment knobs on each side of the luminaire head and sliding the zoom mechanism backwards or forwards as desired.

  • Page 16: Operation And Programming

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual OPERATION AND PROGRAMMING 1. LCD Display and Menu System The SL PAR 155 ZOOM RGBW LED Luminaire’s LCD Display and Menu System provides local control for accessing the following fixture’s settings: •...

  • Page 17: Sl Par 155 Zoom Rgbw Led Luminaire Main Menu Options

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Edit a Preset Edit a Chase Home (menu settings) DMX512 Addressing Return to Main Screen / Return Up One Level LCD Display SL PAR 155 ZOOM RIGHT Arrow Button LEFT Arrow Button DOWN Arrow Button UP Arrow Button...

  • Page 18: Color Filter

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Step 6. Press the Check Mark button to save the preset. You will be asked to confirm your saving operation. Step 7. The preset is now saved and can be recalled via the menu or DMX. Color Filter Color filters are 43 factory made colors that utilize the Harmonize Color Calibration system (refer to "Harmonize...

  • Page 19: Editing User Chases

    The time used to change color values when running a chase. Settings/Security All Showline fixtures have a multiple level locking feature. This allows you to configure the fixture and allow different menu access to multiple users. The menu system can be locked instantly or assigned to power on to a particular lock level.

  • Page 20: Settings/General

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 5: Security Lock Levels Lock Level Menu Functions Affected Level 1 Edit Presets, Edit Chases, and Settings Menu Level 2 Settings Menu Level 3 Use the Up and Down buttons to select security PIN codes. Press the Check button and then use Left and Right and Up Down buttons to assign the pin code.

  • Page 21: Settings/Dmx

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 8: Factory Default Parameters Parameter Description • No - all menu items are able to be restored to factory defaults. Protected • Preset & Chase - user edited Presets and Chases are not able to be restored to fac- tory defaults.

  • Page 22: Password (Passpin)

    • Press the Check Mark button to exit the Status screen. Quick Selection Buttons The Showline menu system includes four quick selection buttons on the top of the menu. These keys provide direct access to common functions and act as shortcuts to main menu items as described in Table 10.

  • Page 23: Harmonize Color Calibration

    When enabled either via DMX or the fixture's menu, the Harmonize technology will ensure that colors match from fixture-to-fixture and pixel-to- pixel. As the Harmonize system matches Showline products, they will all operate in the same color space. Use the Harmonize system when perfect color matching is an essential requirement.

  • Page 24: Dimming Curve Selection

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual 5. Dimming Curve Selection Through the menu, you are able to select one of four dimming curves: • Linear Curve • PL_Curve • S_Curve • Square Curve Linear Curve PL_Curve * DMX Value DMX Value...

  • Page 25: Master / Slave Operational Mode

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual 6. Master / Slave Operational Mode The Master / Slave Operational Mode allows one SL PAR 155 ZOOM RGBW LED Luminaire to act as the "Master" unit and all other connected units are controlled by this unit. When a unit is set to "Slave" mode, it will only listen to and follow any commands sent from a "Master"...

  • Page 26: Dmx Control

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual DMX CONTROL This section contains information for operating the luminaire using DMX control in 16-bit, 8-Bit, or HSIC (Hue, Saturation, Intensity and Color Correction) modes. For Menu options and detailed information, see "LCD Display and Menu System"...
  • Page 27 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 12: SL PAR 155 ZOOM RGBW LED Luminaire DMX Channel Mapping (16-Bit Mode) Select presets, variable color filters or chases as follows: CF_0_Color OFF DMX 69 - 70 CF_1_White 10000K DMX 71 - 72 CF_2_White 8000K DMX 73 - 74 CF_3_White 6500K DMX 75 - 76...

  • Page 28: 8-Bit Modes

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 12: SL PAR 155 ZOOM RGBW LED Luminaire DMX Channel Mapping (16-Bit Mode) Controls strobe operations as follows: Open = DMX 0 - 2 Closed = DMX 3 - 5 Slow Rand = DMX 6 - 7 Med Rand = DMX 8 - 10 Fast Rand = DMX 11 - 12...
  • Page 29 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Enhanced 8-Bit Mode Table 13: SL PAR 155 ZOOM RGBW LED Luminaire DMX Channel Mapping (Enhanced 8-Bit Mode) Default - recom- Parameter Range DMX Range% mended console Description Channel default values Master Intensity 0 - 255...
  • Page 30 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 13: SL PAR 155 ZOOM RGBW LED Luminaire DMX Channel Mapping (Enhanced 8-Bit Mode) Select presets, variable color filters or chases as follows: CF_36_Spring Yellow DMX 141 - 142 CF_37_Yellow DMX 143 - 144 CF_38_Deep Amber DMX 145 - 146 CF_39_Chrome Orange DMX 147 - 148...

  • Page 31: Hsic Mode

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Simple 8-Bit Mode Table 14: SL PAR 155 ZOOM RGBW LED Luminaire DMX Channel Mapping (Simple 8-Bit Mode) Default - recom- Parameter Range DMX Range% mended console Description Channel default values Master Intensity 0 - 255...

  • Page 32: Dmx Control Channel Settings

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 15: SL PAR 155 ZOOM RGBW LED Luminaire DMX Channel Mapping (HSIC Mode) Control Channel functions of the SL Series products. Set control channel value from 0 then turn to desired action.
  • Page 33 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual • To use a timing channel instead of console timing, it is recommended to set the timing channel to the desired value and set cue and/or console cue fade time to zero. A combination of time controls can produce unexpected results. •...
  • Page 34 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 17: SL PAR 155 ZOOM RGBW LED Luminaire Timing Channel Detail = Seconds % Value (unless noted) 10.2 10.4 10.6 10.8 11.2 11.4 11.6 11.8 12.2 12.4 12.6 12.8 13.2 13.4...
  • Page 35 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 17: SL PAR 155 ZOOM RGBW LED Luminaire Timing Channel Detail = Seconds % Value (unless noted) 18.6 18.8 19.2 19.4 19.6 19.8 Sh wline DMX Timing Channel Detail...
  • Page 36 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 17: SL PAR 155 ZOOM RGBW LED Luminaire Timing Channel Detail = Seconds % Value (unless noted) Sh wline DMX CONTROL...
  • Page 37 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 17: SL PAR 155 ZOOM RGBW LED Luminaire Timing Channel Detail = Seconds % Value (unless noted) Sh wline DMX CONTROL...
  • Page 38 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 17: SL PAR 155 ZOOM RGBW LED Luminaire Timing Channel Detail = Seconds % Value (unless noted) 5 Minutes 15 Minutes 30 Minutes 60 Minutes 250* 60mS 251* 80mS 252* 100mS...

  • Page 39: Rdm Parameter Ids

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual RDM PARAMETER IDS 1. SL PAR 155 ZOOM RGBW LED Luminaire RDM Parameter IDs The following tables outline and describe all the RDM parameters IDs associated with SL PAR 155 ZOOM RGBW LED Luminaires.
  • Page 40 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 20: SL PAR 155 ZOOM RGBW LED Luminaire RDM Parameters IDs RDM Parameter IDs Value Comment Implemented Allowed Allowed Category - Product Information ■ ■ DEVICE_INFO 0x0060 ■ PRODUCT_DETAIL_ID_LIST 0x0070 ■...
  • Page 41 SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual Table 20: SL PAR 155 ZOOM RGBW LED Luminaire RDM Parameters IDs RDM Parameter IDs Value Comment Implemented Allowed Allowed ■ ■ POWER_STATE 0x1010 ■ ■ PERFORM_SELFTEST 0x1020 ■ SELF_TEST_DESCRIPTION 0x1021 ■...

  • Page 42: Cleaning And Care

    Step 3. Wipe all debris, dirt, fingerprints, etc. from lens. Step 4. Using a second lint-free lens tissue, wipe off any alcohol residue. 3. Service and Maintenance For all other service and maintenance issues, please contact your local Showline office or an Authorized Service Center. Sh wline...

  • Page 43: Accessories

    Contact your local Showline office or an Authorized Service Center for technical support and service. 4. Accessories Only Showline approved accessories should be used with your SL PAR 155 ZOOM RGBW LED Luminaire. For a list of approved accessories, please see "Accessories" on page 5.

  • Page 44: Technical Specifications Operational Specifications

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual TECHNICAL SPECIFICATIONS 1. Operational Specifications Source: Color RGBW LED Array (x9 - 15 Watt High Power LED Chipsets) Beam Angle: 8 to 40 Degrees (hand adjustable) Light Output: > 3,200 lumens Color Temperature: 2700 - 6,500K (user adjustable) Input Voltage (AC):...

  • Page 45: Luminaire Dimensions

    SL PAR 155 ZOOM RGBW LED Luminaire Installation & User’s Manual 2. Luminaire Dimensions 8.98 in. / 228.0 mm 0.60 in. / 15.0 mm 16.28 in. / 413.5 mm 8.66 in. / 220.0 mm 12.51 in. / 317.7 mm 10.81 in. / 274.6 mm Front View Side View 0.5 in.
