SL PAR 155 ZOOM RGBW LED Luminaire

Connecting SL PAR 155 ZOOM RGBW LED Luminaires to AC Power

If you did not order an AC input cable accessory with your unit, Table 2 describes how to connect power to your SL
PAR 155 ZOOM RGBW LED Luminaire. Field wiring of the SL PAR 155 ZOOM RGBW LED Luminaire is straight
forward. A total of 3 wires/conductors need to be brought to the unit. The following wiring scheme is required:
AC Input Connector
AC Input Connector (on Unit)
Neutral
AC Connector
(on side of unit)
Figure 4: SL PAR 155 ZOOM RGBW LED Luminaire AC Input & Output Connections
CAUTION: In the event the AC input cable of this luminaire is damaged, it must be replaced, by the user, with an
approved cable through an Authorized Showline Dealer or Service Center.
Sh wline
Table 2: SL PAR 155 ZOOM RGBW LED Luminaire AC Input Connections
Wire Color
Brown
Blue
Green/Yellow
Rear of Unit
Main /
Line
Ground / Earth
Installation & User's Manual
Purpose
Main / Line (100 to 240VAC)
Neutral
Ground (Earth)
AC Output (Thru) Connector
Luminaire
AC Output Connector (on Unit)
Main /
Line
AC Connector
(on side of unit)
Ground / Earth
Neutral
9
Connecting Power
