  • Page 1 SL STRIP 10 IP LED LUMINAIRE...

  • Page 2: Showline Offices

    Note: The light source contained in this luminaire shall only be replaced by the manufacturer, authorized service center or suitably qualified person. Document Number: SL STRIP 10 IP LED Luminaire QuickStart Guide Version as of: 24-004-3745-00 Rev1.0 IP LED Luminaire QuickStart Guide SL STRIP 10 ©2014 Philips Group.

  • Page 3: Included Items

    Power Requirements The SL STRIP 10 IP LED Luminaire operates on AC input voltages from 110 to 240 VAC. W ARNING: This unit does not contain an ON/OFF switch. Always disconnect power input cable to completely remove power from unit when not in use.

  • Page 4: Connecting Power

    D i r e c t connection to an AC power source using an AC input cable. For wiring of AC input connector, refer to LED Luminaire to AC Power C o n n e ction from the AC output of another SL STRIP 10 IP LED Luminaire. When using this method, it is very important not to connect any other type of equipment.

  • Page 5: Connecting To The Dmx Network

    Mounting Luminaire SL STRIP 10 IP LED Luminaires are provided with the ability to fix the unit on the Mount assemblies by the tilt knobs. If the units are mounted in a hanging application, it is recommended (and may be required by local and national safety codes) to use and install a safety cable (sold separately).

  • Page 6: Lcd Display And Menu System

    Figure 1-3: Mounting Luminaire LCD Display and Menu System SL STRIP 10 IP LED Luminaire The SL STRIP 10 IP LED Luminaire’s LCD Display and Menu System provides local control for accessing the following fixture’s settings: Effects (Chases - preloaded and user defined)

  • Page 7: Lcd Display And Menu System Operation

    SL STRIP 10 IP LED Luminaire QuickStart Guide LCD Display and Menu System Operation The LCD Display Menu system consists of several categories. Use the MODE Button to access and make changes to the menu items. When the desired menu item is reached, press the desired MENU Button to display the menu options and to navigate and configure the menu options as required.
  • Page 8 Dallas 10911 Petal Street Dalls, TX 75238 Tel: +1 214-647-7880 Fax: +1214-647-8031 Asia Unit C, 14/F, Roxy Industrial Centre No. 41-49 Kwai Cheong Road Kwai Chung, N.T., Hong Kong Tel: +852 2796 9786 Fax: +852 2798 6545 Auckland 19-21 Kawana Street Northcote, Auckland 0627 New Zealand Tel: +64 9 481 0100...
