Installation & User's Manual

3. Connecting to the DMX512 Network

Basic DMX512 installation consists of connecting multiple SL PAR 155 ZOOM RGBW LED Luminaires together
(up to 32 luminaires) in "daisy-chain" fashion. A cable runs from the control console (or DMX512 control source) to
the DMX connector on the first SL PAR 155 ZOOM RGBW LED Luminaire. Another cable runs from the other
DMX connector on the first unit to a DMX connector on the next SL PAR 155 ZOOM RGBW LED Luminaire (or
DMX512 device to be controlled).
Figure 5: SL PAR 155 ZOOM RGBW LED Luminaire DMX512 Input / Output Connections
Note: For more information on DMX512 networking and systems, refer to
page 1. For SL PAR 155 ZOOM RGBW LED Luminaire DMX Mapping, refer to
DMX512
(from console or
control device)
1 0
INSTALLATION AND SET UP
Rear of Unit
DMX512 / RDM
Input Connector
DMX512
to second luminaire)
Note: Remaining pins on each connector are not used.
Figure 6: SL PAR 155 ZOOM RGBW LED Luminaire - DMX512 Connections
SL PAR 155 ZOOM RGBW LED Luminaire
DMX512
(out from first
DMX512 Connections
DMX512 Signal XLR Pin
Common (Drain) 1
DMX512 - 2
DMX512 + 3
DMX512 / RDM
Output Connector
"Additional Resources for DMX512" on
"DMX CONTROL" on page
(out to the next luminaire or
DMX512 controlled device)
Sh wline
Luminaire
24.
