Installation & User's Manual
OPERATION AND PROGRAMMING
1. LCD Display and Menu System
The SL PAR 155 ZOOM RGBW LED Luminaire's LCD Display and Menu System provides local control for
accessing the following fixture's settings:
• Presets (Standard and User Defined)
• Color Filters
• Effects (Chases - preloaded and user defined)
• Strobe / Timing
• Fixture Settings
• Fixture Lockout (to prevent changes)
• Password Setting
• Current Fixture Operational Status
• Setting the DMX512 Address
Note: If there are multiple luminaires in a system, changes would need to be made at each LCD Menu as desired. For
SL PAR 155 ZOOM RGBW LED Luminaire menu structure, see
Menu Options" on page
Upon power up, the LCD will display the main screen showing the product type/name. If DMX is enabled, the
programmed address will appear after power up.
2. LCD Display and Menu System Operation
The LCD Display Menu system consists of several categories. Use the Menu Buttons to access and make changes to
the menu items. When the desired menu item is reached, press the desired Menu Button to display the menu options
and to navigate and configure the menu options as required.
To navigate and access menu settings/selections:
Step 1. Make sure unit is powered and turned on.
Step 2. Press the desired button (as shown in Figure 11 on page 15) to access menu categories.
Step 3. Use UP | DOWN | LEFT | RIGHT arrow buttons to navigate through the various options and settings.
Step 4. Make changes as desired.
Step 5. Press CHECK MARK (OK) button to accept changes.
1 4
OPERATION AND PROGRAMMING
15.
SL PAR 155 ZOOM RGBW LED Luminaire
"SL PAR 155 ZOOM RGBW LED Luminaire Main
