Installation & User's Manual

SL PAR 155 ZOOM RGBW LED LUMINAIRE OVERVIEW

1. SL PAR 155 ZOOM RGBW LED Luminaire Components

Common Luminaire Components

Front of Unit
High Intensity LED Array
Yoke (Tilt) Position
Locking Handle
Zoom Adjustment Knobs
* Truss hooks and clamps are sold separately.
6
SL PAR 155 ZOOM RGBW LED LUMINAIRE OVERVIEW
Truss Hook / Clamp *
Attachment Point
Figure 2: SL PAR 155 ZOOM RGBW LED Luminaire Common Components
SL PAR 155 ZOOM RGBW LED Luminaire
Yoke Assembly
AC Input
DMX512 / RDM Input
LCD Display / Menu System
DMX512 / RDM Output
Rear of Unit
AC Output
Accessory Holder Clip
Accessory Holder
Luminaire Head Assembly
