Step 6. Press the Check Mark button to save the preset. You will be asked to confirm your saving operation.
Step 7. The preset is now saved and can be recalled via the menu or DMX.

Color Filter

Color filters are 43 factory made colors that utilize the Harmonize Color Calibration system (refer to
Color Calibration" on page 21
To recall a color filter from the menu:
Step 1. Select Color Filter from the main menu
Step 2. The top indicates the current color filter or Off, when this field is selected (highlighted in blue), use the left
and right buttons to scroll through all color filters.
Step 3. Use the Up and Down arrow keys to toggle to the Master Intensity field. Use the Left and Right arrow keys
to adjust the Master Intensity.
Step 4. The menu will display a graphical indication of the color along with the color name.
Note: The color filter will remain ON until you select a preset, chase, other color filter or send the unit DMX.

Effects

Effects are chases stored values of the luminaire's LED settings that can be recalled via the menu system or DMX.
There are 10 factory defined chases and eight user adjustable chases. You can adjust the master intensity, speed, and
fade values for any of the 18 chases.
Use the Up and Down buttons to select parameters and the Left and Right buttons to assign the different general
fixture settings. When finished, press the Check button to exit the menu level. The adjustable parameters are
described in Table 3.
User Chase / Built-in Chase
Master Intensity
Total Steps
Speed
Fade
1 6
OPERATION AND PROGRAMMING
for more information). They can be recalled via the menu system or DMX.
Parameter
Select from the 18 different chases.
Adjust the master intensity for ALL chases.
Displays the total steps used by the chase. This field is not editable.
The total time each step of the chase will be recalled.
The percentage of the time assigned by the speed that is crossfaded between steps.
SL PAR 155 ZOOM RGBW LED Luminaire
Table 3: Effects Parameters
Description
