WARNING:
AVERTISSEMENT: Risque potentiel de blessure grave ou de mort. Le
System Compatibility
The FOX T USW 203 supports Plus or Non-Plus mode transmission for compatibility with
FOX receivers. Devices in Plus mode are only compatible with other devices in Plus mode.
Use SIS commands (see
Control Program (see
•
•
FOXBOX Rx DVI Plus
FOXBOX Rx HDMI
FOXBOX SR HDMI
PowerCage FOX Rx DVI Plus
PowerCage FOX Rx HDMI
PowerCage FOX SR HDMI
FOX II R DP
Cable Transmission Modes
The switcher is further categorized by the type of fiber optic cable, multimode (MM) or
singlemode (SM), which define the effective range of transmission
•
•
Key Features
Long distance fiber optics transmission — Transmits HDMI or analog video, stereo
audio, and RS-232 signals up to 30 km when using singlemode fiber optic cabling.
Inputs — Include two female HDMI type-A connectors, one RGBHV/RGBS or HD
component on 15-pin HD connector, and one unbalanced analog stereo audio on a 3.5 mm
stereo mini-jack.
Potential risk of severe injury. The FOX T USW 203 outputs continuous
invisible light, which may be harmful to the eyes; use with caution.
FOX T USW 203 émet une lumière invisible en continu qui peut être dangereux pour
les yeux, à utiliser avec précaution.
•
Do not look into the rear panel fiber optic cable connectors or into the fiber optic
cables themselves.
•
Ne regardez pas dans les connecteurs de câble fibre optique sur le panneau arrière
ou dans les câbles fibre optique eux-mêmes.
•
Plug the attached dust caps into the optical transceivers when the fiber cable is
unplugged.
•
Branchez les protections contre la poussière dans l'ensemble émetteur/récepteur
lorsque le câble fibre optique est débranché.
Plus mode transmission
Plus Mode Transmission panel
Non-Plus — Supports resolutions from 640x480 up to 1600x1200 @ 60 Hz, including
480p up to 1080p @ 60 Hz. Embedded audio is not supported, but analog audio is
supported and HDCP compliant.
Plus — Supports all resolutions supported in non-plus mode, plus 1920x1200 and
2K (2048x1080) @ 60 Hz. Embedded audio and analog audio are supported and are
both HDCP compliant.
Supported Receivers
Plus Mode
Multimode — Long distance, up to 2 km (6,560 feet) (depending on the fiber cable)
Singlemode — Very long distance, up to 30 km (18.75 miles)
on page 19) or the FOX Extenders
on page 34) to change the mode.
Non-Plus Mode
FOXBOX Rx VGA
FOXBOX Rx DVI
FOX 500 DVI Rx
FOX 500 Rx
PowerCage FOX Rx VGA
PowerCage FOX Rx DVI
FOX T USW 203 Universal Switcher • Introduction
