RESET BUTTON

2
Pressing the reset button causes the matrix to stop its current activity and to
restart. The same configuration that was active before you reset the system will be
active after you reset it.
During the reset, configuration information reloads to the matrix's operational
memory from its non-volatile memory and the matrix starts running again from
the beginning.

OK LIGHT

3
When flashing, the "OK" light indicates that the Eclipse-32 matrix is running
successfully.

CONFIGURATION "CONFIG" BUTTON

4
The Eclipse-32 matrix can hold four complete system configurations in its
operational memory. You can activate one of the four configurations using the
CONFIG button on the matrix's front panel.
When one of the four configurations is active, its front-panel light illuminates
steadily.
To select a new configuration:
1. Repeatedly tap the CONFIG button until the desired configuration's light
(1,2,3, or 4) starts flashing.
2. While the desired configuration's light flashes, press and hold the
configuration button for three seconds, until the light stops flashing, and
illuminates steadily.
The selected configuration then becomes the system's active operational
configuration.
If you choose an invalid or blank configuration, all four configuration lights
steadily illuminate at the same time for about a second. The currently active
configuration will continue to operate and its front-panel light steadily
illuminates after the other lights go out.

CONFIGURATION STATUS LIGHTS

5
The four configuration status lights indicate which of the four onboard
configurations is currently active. The currently active configuration's light
illuminates steadily.

POWER SUPPLY ALARM LIGHTS (1 AND 2)

6
An Eclipse-32 matrix has two internal power supply units. One power supply
unit can power an entire matrix; the second unit provides a backup in case of an
equipment failure.
