5
E C L I P S E - 3 2 M A T R I X I N S T R U C T I O N M A N U A L

SPECIFICATIONS

0 dBu is referenced to 0.775 volts RMS
General
Height
Width
Depth
Weight
Power Consumption
Number of Station Compatible Ports
Number of Analog Audio Ports
Number of Expansion Modules
Number of Power Supply Units
Maximum Number of Ports Per System 72 with 2 Eclipse-32 units; 64 station ports
Matrix Performance
Sample Rate
Resolution
Frequency Response @ 48 kHz sampling 30 Hz – 22 kHz ± 3 dBu
Crosstalk (adjacent channel)
Nominal Level
Matrix headroom
Distortion
Off Noise
On Noise
Key Response, Intra-System
Linked Systems
Temperature
Humidity, Maximum
Matrix Interfaces
GPI inputs
GPI outputs (relays)
GPI connector
GPO connector
External GPI-6/RLY-6
44 mm or 1.75 inches (1 RU)
482 mm (19 inches)
300 mm (12 inches)
5 kg max.
500 W Max. per inlet
32
4
1
2
48 kHz
24 bit
<–70 dBu
0 dBu
18 dBu
<0.05 %, @ 0 dBu, 300 Hz to 10 kHz;
<0.1 %, @ 0 dBu, 100 Hz to 20 kHz
<–98 dBu relative to +18 dBu,
20 Hz - 22kHz
<–83 dB relative to +18 dBu, 20 Hz - 22 kHz
<40 ms for audio route
<60 ms for audio between matrices
°
0 to +40 C, ambient;
° °
-55 to +70 C, storage
90% non-condensing
8 total; opto-isolated
8 total; isolated relay contacts
25-pin D-type socket on rear panel
25-pin D-type plug on rear panel
RJ-45 on rear panel
5 - 1
