CONNECTING TO A SECOND ECLIPSE MATRIX

6
You connect shielded category-5 (CAT-5) cable from the "base loop" socket of
one Eclipse-32 matrix to the "base loop" socket of a second Eclipse-32 matrix to
form one non-blocking 64-port Eclipse matrix system. The cable connecting the
two matrices can be up to 1 meter (3.28 feet) long.

CONNECTING TO A LOCAL AREA NETWORK

7
The RJ-45 socket labeled "LAN" connects a local area network (LAN) to the
Eclipse-32 matrix through a standard Ethernet connection.
