BV50
OPERATIONS
MANUAL
Innovative Technology assume no responsibility for errors, omissions, or damages
resulting from the use of information contained within this manual.
Copyright Innovative Technology Ltd 2014
GA717-3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BV50 and is the answer not in the manual?

Questions and answers

Григорий
May 10, 2025

Здравствуйте, в купюроприемнике BV-50 прижимную планку, что можно сделать?

Subscribe to Our Youtube Channel

Summary of Contents for Innovative Technology BV50

  • Page 1 BV50 OPERATIONS MANUAL Innovative Technology assume no responsibility for errors, omissions, or damages resulting from the use of information contained within this manual. Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 2: Table Of Contents

    9.3 INTERNET WEB SUPPORT ........................19 9.4 EMAIL SUPPORT ............................19 10 APPENDIX ..............................20 10.1 APPENDIX A – BV50 ORDER FORM ...................... 20 10.2 APPENDIX B – DIMENSION DRAWING ....................21 10.3 APPENDIX C – CASHBOX INFORMATION ....................22 10.4 APPENDIX D –...
  • Page 3: Introduction

    BV100 Operations Manual 1 INTRODUCTION This manual describes the operation of the BV50 Bill Acceptor programmed with Firmware Version 4.04 or greater. CAUTIONS: • THIS PRODUCT MUST BE FITTED WITH A 2 AMP TIME DELAY FUSE BEFORE USE. • DUE TO DIFFERENT BILL CYCLE TIMES THERE MAY BE TIMING DIFFERENCES FROM THE NV PRODUCTS.
  • Page 4: Environment And Power Requirements

    0 V to + 0.5 V +3.7 V + 12 V 0.6 V Pull up voltage of host interface Outputs with 2K2 pull up Maximum Current Sink 50mA per output Table 3 – Interface Logic Levels Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 5: General Description

    Currency The BV50 Bill Acceptor leaves the factory pre-set to at least one currency so that it is ready for immediate installation. If it is required to change the currency dataset this may be done using the PC based Validator Management software or with the DA3 Validator Programming System, see chapter 5 - Reprogramming the BV50 for more details.
  • Page 6 Cashbox Capacity – The required capacity of the cashbox. Sizes available are 300, 500, 700 or 900. ccTalk Encryption Key – The required ccTalk encryption key if the selected interface is CCT. If left blank, a key of 123456 will be used. Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 7: Machine Interfaces

    4.2.1 POINTS AND BUTTONS 4.2.2 INTERFACE PIN DETAILS The function of pins 1-8 changes according to which machine interface is being used. See the individual interface descriptions for details. Figure 3 – BV50 Cable connections Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 8: Configuration Button Functions

    Input details) Inhibit 4 Input Busy Output Active LOW when the BV50 is transporting, reading or stacking a note Escrow Input Enable the escrow function by holding LOW in Parallel, Pulse or Binary modes (See Appendix E – Escrow Function)
  • Page 9: Hardware Options

    LED will flash rapidly to indicate that the SSP interface is being loaded. Once this process has finished the BV50 will reset. The BV50 will now be in Programming Mode (SSP) and allow connection to a PC via a DA1 or DA2 adapter or connection to a DA3.
  • Page 10: Cctalk

    3-wire bus (+12V, 0V and Data). To use the BV50 in ccTalk mode, pins 1 and 5 (Tx and Rx) must be connected together as the data line.
  • Page 11: Mdb (Multi Drop Bus)

    Machine Controller (VMC) has the capability of communicating with 32 peripherals or slaves. BV50 Connections: To use the BV50 in MDB mode, an MDB in-line module is required. The in-line module regulates the power supply and opto-isolates the communication lines.
  • Page 12: Parallel

    If all four inhibits are high simultaneously then the BV50 will be disabled. In this state the bezel will not illuminate and if a bill is inserted the motor will run in reverse preventing the insertion of the bill.
  • Page 13: Pulse

    BV100 Operations Manual 4.3.5 PULSE In Pulse mode the BV50 outputs a number of pulses on Vend 1. The number of pulses for each channel is different and set to default values within the dataset. The number of pulses and duration can be modified using the Validator Manager software.
  • Page 14: Binary

    BV100 Operations Manual 4.3.6 BINARY In Binary mode, the BV50 will issue a binary pattern on vend lines 1 to as shown in Table 12 - Binary Credit Outputs. A maximum of 15 channels can be used. Vend Vend Vend...
  • Page 15: Re-Programming The Bv50

    • Use diagnostic functions to check bill acceptors operation The BV50 is connected to either the serial port of a PC using a DA1 kit, or the USB port using a DA2 kit and set to programming mode using the configuration.
  • Page 16: Validator Programming System (Da3)

    For full DA3 operation and functionality details please refer to the DA3 User Manual (Document number GA339). When programming a BV50 using the DA3 BNV Override Download function, the firmware interface is unchanged. A Configuration Card must be used after re-programming if a different interface is required.
  • Page 17: Low Power Option

    The BV50 goes into low power mode approximately 6 seconds after the bill acceptor is powered up and remains in this state until a bill is entered (Time A). Following a bill insertion the BV50 returns to Low Power mode approximately 1 second after the Busy line goes High (Time B).
  • Page 18: Maintenance And Re-Initialisation

    7 MAINTENANCE AND RE-INITIALISATION 7.1 ROUTINE MAINTENANCE The BV50 Bill Acceptor has been designed to minimise any performance variation over time. Much of this is achieved by careful hardware and software design. However, depending upon the environment the BV50 may at some time require cleaning.
  • Page 19: Diagnostics

    Motor continues to run Foreign object or bill is Ensure the note path is clear and stuck in the note path reset the bill acceptor. It may also be necessary to reset the host machine. Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 20: Support

    9.3 INTERNET WEB SUPPORT The Bellis Technology website provides the means to download new and updated currency sets and new versions of firmware for the BV50. You can obtain these along with technical bulletins by visiting www.bellis-technology.com. 9.4 EMAIL SUPPORT If the data you require is not available over the Internet Bellis Technology supports an e-mail system to help customers with unusual requirements.
  • Page 21: Appendix

    10.1 APPENDIX A – BV50 ORDER FORM To order the BV50, please print and fill the order form and send it to your nearest office by fax or email. Contact information is available in the introduction chapter of this document or on our website. If you do...
  • Page 22: Appendix B - Dimension Drawing

    BV100 Operations Manual 10.2 APPENDIX B – DIMENSION DRAWING The following page contains drawing number GA800 which shows the dimension of the BV50 including positioning of the mounting slots. ACCEPTS BILLS: UP TO 66 mm x 160 mm LONG SUPPLY AND POWER CONSUMPTION: VOLTAGE: 10.8 - 13.2 V...
  • Page 23: Appendix C - Cashbox Information

    10.3 APPENDIX C – CASHBOX INFORMATION There are different capacity cash boxes available for the BV50. The standard cash box will hold approximately 300 used bills. Cash box spacers can be added at the factory to increase the capacity. Each spacer will add an extra 200 bill capacity with a maximum of 3 spacers.
  • Page 24 Stay inside the lines and fill boxes completely in like the example below. 3) Power up BV50 and allow it to reset. 4) Press the Configuration button once on the BV50 to access the Configuration Mode. The BV50 bezel LEDs should now be flashing at 1 second intervals.
  • Page 25: Appendix E - Escrow Function

    10.5 APPENDIX E – ESCROW FUNCTION The BV50 has a single bill escrow facility (pin 10) used in Parallel, Pulse and Binary modes. This allows the bill acceptor to hold onto the bill once accepted, and then only stack the bill in the cash box when the host machine confirms that the Vend operation has been completed.
  • Page 26: Appendix F - Implemented Cctalk Commands

    BV50 OPERATIONS MANUAL DRAWING NO AUTHOR DATE FORMAT GA820 18/03/08 MS Word 2000 ISSUE RELEASE DATE MODIFIED BY COMMENTS 18/03/08 First Draft 17/09/08 Second Draft. Added configuration card appendix and re-ordered chapters 14/08/2014 General Update Copyright Innovative Technology Ltd 2014 GA717-3...
