5.2 - Windowing

Users may optimize the CR2500 decode zone if their application only requires one bar code format. If the size and density

of the bar codes to be scanned are consistent, please select the setting below that best describes your environment.

1-Dimensional Codes ONLY (1024 X 200 pixels)

Caution: It may be more difﬁ cult to read other codes while in this setting. You must have the

reader farther away than normal.

Small 2-Dimensional Codes (480 x 480 pixels)

Large 2-Dimensional Codes (640 x 640 pixels)

5.3 - Mirror Decoding

Scan the following codes to enable/disable the mirroring feature:

Note: The Mirroring feature allows the CR2500 to read codes as they are seen through a mirror (inversed 180°). If the

Mirroring feature is enabled, non-mirrored reading ability will be disabled.

Anti-glare technology improves performance on highly reﬂ ective surfaces. The CR2500 will detect when the glare from the

illumination LEDs is preventing the reader from being able to decode the bar code. Once glare is detected the reader will

attempt to control the illumination LEDs to remove or reduce the glare thereby improving performance.

Enable Anti-glare (default)

Save Settings

(continued)

Off (Default)

Disable Anti-glare

Medium 2-Dimensional Codes (512 x 512 pixels)

Reset to Default Setting (1024 X 640 pixels)

C004386_03_CR2500_ User_Manual
