Users may optimize the CR2 decode zone if their application only requires one bar code format. If the size and density of

the bar codes to be scanned are consistent, please select the setting below that best describes your environment.

1-Dimensional Codes ONLY (1024 x 200 pixels)

Caution: It may be more difﬁ cult to read other codes while in this setting. You must have the

reader farther away than normal.

Small 2-Dimensional Codes

Large 2-Dimensional Codes

5.3 - Mirror Decoding

Scan the following codes to enable/disable the mirroring feature:

Note: The Mirroring feature allows the CR2 to read codes as they are seen through a mirror (inversed 180°). If

the Mirroring feature is enabled, non-mirrored reading ability will be disabled.

Save Settings

Medium 2-Dimensional Codes

(480 x 480 pixels)

Reset to Default Setting

(640 x 640 pixels)

Off (Default)

(512 x 512 pixels)

(1024 x 640 pixels)

C001537_15_CR2_User_Manual
