Lucent Technologies Host-Based Controller Modem AT Data Addendum page 5

Data Addendum
June 15, 1998
AT Command Summary (continued)
Result Code
CONNECT 29333 EC*
CONNECT 30666 EC*
CONNECT 33333 EC*
CONNECT 34666 EC*
CONNECT 37333 EC*
CONNECT 38666 EC*
CONNECT 41333 EC*
CONNECT 42666 EC*
CONNECT 45333 EC*
CONNECT 46666 EC*
CONNECT 49333 EC*
CONNECT 50666 EC*
CONNECT 53333 EC*
CONNECT 54666 EC*
* EC only appears when the extended result codes configuration option is enabled. EC is replaced by one of the following symbols,
depending upon the error control method used:
V42bis—V.42 error control and V.42bis data compression.
V42—V.42 error control only.
MNP 5—MNP class 4 error control and MNP class 5 data compression.
MNP 4—MNP class 4 error control only.
NoEC—No error control protocol.
Version 1.0
Numeric Description
101 Connection at 29333 bit/s (V.90 mode)
102 Connection at 30666 bit/s (V.90 mode)
103 Connection at 33333 bit/s (V.90 mode)
104 Connection at 34666 bit/s (V.90 mode)
105 Connection at 37333 bit/s (V.90 mode)
106 Connection at 38666 bit/s (V.90 mode)
107 Connection at 41333 bit/s (V.90 mode)
108 Connection at 42666 bit/s (V.90 mode)
109 Connection at 45333 bit/s (V.90 mode)
110 Connection at 46666 bit/s (V.90 mode)
111 Connection at 49333 bit/s (V.90 mode)
112 Connection at 50666 bit/s (V.90 mode)
113 Connection at 53333 bit/s (V.90 mode)
114 Connection at 54666 bits/s (V.90 mode)
Lucent Technologies Inc.
Host-Based Controller Modem
AT Command Set
5
