- Page 1 ® CellPipe 20A-USB Series User Guide May 2004...
- Page 2 Before handling any Lucent Access Networks hardware product, read the Edge Access Safety and Compliance Guide, which can be found at http://www.lucentdocs.com/ins. See the warranty card included in your product package for the limited warranty that Lucent Technologies provides for its products. See Appendix C for further information on regulatory compliance.
-
Page 3: Customer Service
Customer Service Lucent Technologies is the value added reseller (VAR) of certain CellPipe products. To ensure you receive the latest and most up-to-date information in a timely manner, Lucent is providing you with the latest original equipment manufacturer (OEM) documentation. Thus, references to both Lucent and the OEM might appear in the documentation. -
Page 4: Obtaining Assistance Through Email Or The Internet
Obtaining assistance through email or the Internet If your services agreement allows, you can communicate directly with a technical engineer through Email Technical Support or a Live Chat. Select one of these sites when you log in to http://www.lucent.com/support. Calling the technical assistance center (TAC) If you cannot find an answer through the tools and information of Lucent OnLine Customer Support or if you have a very urgent need, contact TAC. -
Page 5: Preventing Static Discharge Damage
Preventing static discharge damage Semiconductor devices can be easily and permanently damaged due to electrostatic discharge during installation or removal. A person walking across a floor can generate electrostatic voltages in excess of 5000V. Although you might not notice a discharge of less than 3500V, discharges below 100V can damage semiconductor components. -
Page 6: Remove Plastics From Your Work Area
Use the following two simple tests to verify that the wrist strap is functioning properly: • Measure the resistance between the wrist strap and its grounding plug. Overall resistance between these two points must be approximately 1 megohm. If it is not, replace the strap. -
Page 7: Table Of Contents
Contents Contents ® CellPipe 20A-USB Series ........................i ............................UIDE Customer Service ........................... i ....................INDING INFORMATION AND SOFTWARE ......................BTAINING TECHNICAL ASSISTANCE Obtaining assistance through email or the Internet................ii Calling the technical assistance center (TAC) ..................ii Preventing static discharge damage....................iii .......................... - Page 8 ® CellPipe 20A-USB Series User Guide...
-
Page 9: Chapter 1 Overview
Chapter 1 Overview Chapter 1 Overview The CellPipe® 20A-USB Modem is a full-featured plug-and-play modem, supporting multiple line codes and ATM protocols for worldwide DSL markets. Based on GlobespanVirata’s low power Centragate chipset and combined with the PC driver that utilizes the host resources, The CellPipe®... -
Page 10: Packaging
Chapter 1 Overview Packaging This package consists of the following items: The CellPipe® 20A-USB Modem USB Cable RJ-11 Cable CD-ROM includes User’s Manual and USB Drivers. In order to reduce the risk of fire, electric shock and injury, please adhere to the following safety guidelines. -
Page 11: Appearance
Chapter 1 Overview Appearance Front Panel Label Status Color Description Power is supplied through Green USB cable. Green ADSL link is ready. Blinking Green Data transmitting/receiving Rear Panel Label Description Connect to a USB port on a PC. Connect to the ADSL wall outlet. ®... - Page 12 Chapter 1 Overview ® CellPipe 20A-USB Series User Guide...
-
Page 13: Chapter 2 Hardware Installation
Chapter 2 Hardware Installation Chapter 2 Hardware Installation The CellPipe 20A-USB unit is connected to the USB port on your computer via a standard USB cable. Install the CellPipe 20A-USB as follows: 1. Turn on your computer. 2. Insert the rectangular end of the USB cable into the USB port of your computer. 3. - Page 14 Chapter 2 Hardware Installation ® CellPipe 20A-USB Series User Guide...
-
Page 15: Chapter 3 Software Installation
Chapter 3 Software Installation Chapter 3 Software Installation The installation steps listed below are the same for Windows 98 /98SE /ME /2000 /XP. 1. While Windows is running, insert the Installation CD into your CD-ROM drive. If the installation does not begin automatically, Right Click on the Start button, and choose Explore. - Page 16 Chapter 3 Software Installation 3. After reading the license agreement, click on the Accept button to continue. You will then see the Select Driver Type screen. 4. Select LAN Driver or WAN Driver based on your ISP settings and click on the Next button. You will then see the Communications Settings Screen.
- Page 17 Chapter 3 Software Installation 6. Click on the Next button to continue. You will then see the Ready to Install screen. 7. This screen displays a summary of the settings you have selected. Make sure that the settings are correct and then click on the Next button, otherwise click on the Back button to change the settings.
- Page 18 Chapter 3 Software Installation Then you will see the Reboot screen. 10. The setup is almost complete. Select the Yes, reboot the computer now radio button and then click on the Close button. Your computer will then restart. 11. Once your computer has restarted, you will see the Finished screen. Click on the Finish button to complete the installation.
-
Page 19: Chapter 4 Customizing Communication Settings
Chapter 4 Customizing Communication Settings Chapter 4 Customizing Communication Settings In order to change the communication settings in Windows 98/ 98SE /ME /XP follow the steps below. NOTE: The CellPipe® 20A-USB Modem must be plugged into the PC in order the change the communications settings. - Page 20 Chapter 4 Customizing Communication Settings 3. Select the Yes, reboot the computer now radio button and click on the Close button. Your computer will then restart to complete the configuration. After the computer has restarted you will see a DSL Status icon on your desktop in the system tray.
-
Page 21: Chapter 5 Dsl Status
Chapter 5 DSL Status Chapter 5 DSL Status In order to view the DSL Status of the CellPipe® 20A-USB Modem in Windows 98/ 98SE /ME /XP, follow the steps below. 1. Click on the Start button > Programs > USB ADSL Modem > DSL Status. You will then see the DSL Status window. - Page 22 Chapter 5 DSL Status ® CellPipe 20A-USB Series User Guide...
-
Page 23: Chapter 6 Device Removal
Chapter 6 Device Removal Chapter 6 Device Removal In order to uninstall the CellPipe® 20A-USB Modem in Windows 98/ 98SE /ME /XP, follow the steps below. Note: The CellPipe® 20A-USB Modem must be plugged into the PC in order to uninstall the drivers. - Page 24 Chapter 6 Device Removal 5. Unplug the modem from your computer, and click on the OK button. You will then see the Reboot screen. 6. Select the Yes, reboot the computer now radio button and click on the Close button. Your computer will then restart, as the uninstallation is complete.
-
Page 25: Appendix A Specifications
Appendix A Specifications Appendix A Specifications A1. Hardware Specifications LAN Interface • Type – Standard USB Version 1.1 • Connector – USB Type B. ADSL Line Interface • Line code: ITU G.992.1 (G.dmt) Annex A/ B*/ C*, G.992.2 (G.lite) Annex A/ C*, G.994.1 (G.hs), and ANSI T1.413 issue 2 over POTS or ISDN line. -
Page 26: A2. Software Specifications
Appendix A Specifications A2. Software Specifications • ATM cells over ADSL; AAL5, OAM, and RM. • Payload Encapsulation: RFC1483 Multi-protocol Encapsulation over AAL5 RFC1577 Classical IP and ARP over ATM (IPoA) RFC2364 PPP over AAL5 (PPPoA) RFC2516 Transmitting PPP over Ethernet (PPPoE) •... -
Page 27: Appendix B Regulatory Compliance
Listed Personal Computer.” European Community (EC) RTTE Compliance Hereby, Lucent Technologies, declares that the equipment documented in this publication is in compliance with the essential requirements and other relevant provisions of the Radio and Telecommunications Technical Equipment (RTTE) Directive 1999/5/EC.
