Lucent Technologies Host-Based Controller Modem AT Data Addendum page 26

Host-Based Modem
AT Command Set
Test and Debug AT Commands (continued)
41 3 digits
42 2 digits
43 2 digits
44 Table 8
45 4 digits
46-4F
50 1 digit
51 1 digit
52 8 digits 0-FFFFFFFF
53 8 digits 0-FFFFFFFF
54 8 digits
55 8 digits
56 8 digits 0-FFFFFFFF
57 8 digits 0-FFFFFFFF
58 8 digits
59 8 digits
5A-5F
60 Tables 9-10
61 2 digits
62-7F
80-FF
Table 2 - Call Setup Result Codes
Code Definition
0 No previous call (modem log has been cleared since any previous calls)
1 No dial tone detected
2 Reorder signal detected, network busy
3 Busy signal detected
4 No recognized signal detected
5 Voice detected
6 Text telephone signal detected (see V.18)
7 Data Answering signal detected (e.g. V.25 ANS, V.8 ANSam)
8 Data Calling signal detected (e.g. V.25 CT, V.8 CI)
9 Fax Answering signal detected (e.g. T.30 CED, DIS)
A Fax Calling signal detected (e.g. T.30 CNG)
B V.8bis signal detected
C-F Reserved
Table 6 - gstnModulationSchemeActive from 3.7.2/V.58
Value (hex) Description
0 V.17
1 V.21
2 V.22
3 V.22bis
4 V.23 Constant Carrier (1200/75)
5 V.23 Switched Carrier (half duplex)
6 V.26bis
7 V.26ter
8 V.27ter
9 V.29 HD
A V.32
B V.32bis
C V.34
D V.34 HD
E V.pcm (asymmetric)
F V.pcm (symmetric)
E-7F Reserved (V.58)
80 "X2™"
81 "K56FLEX™"
82 "V.FC"
83 "V.32terbo"
80-FF Reserved for mfgs
26
0-400 Error Control frame size
0-FF Error control link timeouts
0-FF Error control link NAKs
0-1 Compression Negotiation Result (Note 7)
0-200 Compression dictionary size (Note 7)
Reserved
0-2 Transmit flow control: 0 = off; 1 = DC1/DC3; 2 = V.24 ckt 106/133
0-2 Receive flow control: 0 = off; 1 = DC1/DC3; 2 = V.24 ckt 106/133
Transmit characters sent from DTE (Note 8)
Received characters sent to DTE (Note 8)
0-FFFF Transmit characters lost (data overrun errors from DTE) (Note 9)
0-FFFF Received characters lost (data overrun errors to DTE) (Note 9)
Transmit Frame count, if error control protocol running (Note 8)
Received Frame count, if error control protocol running (Note 8)
0-FFFF Transmit Frame error count, if error control protocol running (Note 9)
0-FFFF Received Frame error count, if error control protocol running (Note 9)
Reserved
Note 10 Termination Cause
0-FF Call Waiting event count
Reserved for future versions of this specification
Reserved for manufacturer proprietary keys
Lucent Technologies Inc.
Implemented
X
X
X
Data Addendum
June 15, 1998
X
X
X
X
X
X
X
Implemented
X
X
X
X
X
Version 1.0
