Test and Debug AT Commands (continued)
The modem may generate a single line or multiple lines, based on modem capabilities and call results, followed
by a standard OK final result code. For example, if call setup failed, only that result is useful. Each information
text line shall be formatted as follows, including one or more key=value pairs:
DIAG <token key=value [[key=value] [key=value]] ...>
DIAG 5 characters, hex: 44, 49, 41, 47, 20
< left angle bracket (less than sign), hex: 3C
token unique 32-bit hexadecimal string 2A4D3263, hex: 32, 41, 34, 44, 33, 32, 36, 33
space space character, hex 20
key single hexadecimal numeric digit, see Table 1
= equal sign, hex: 3D
value any string as defined below (Tables 1-3, etc.)
> right angle bracket (greater than sign), hex: 3E
Unless otherwise noted, all values are hexadecimal numbers. Any numeric values from tables in ITU V.58 are
converted to hexadecimal. Multi-digit values are reported MSD first. Leading 0's may be deleted.
The following table 1 includes all the items listed in Microsoft's specification for the AT#UD command. Within these
items, the one that has a check mark in the "Implemented" column is implemented in this release of the modem
product. For an item that has an extra option table, please check the corresponding option table to see exactly
which option has been implemented.
Key value(s)
0 2 digits
1 Table 2
2 Table 3
3 Table 4
4 String
5 String
6-F
10 2 digits
11 2 digits
12 2 digits
13 2 digits
14 2 digits
15 2 digits
16 4 digits
17 2 digits
18 Table 5
19-1F
20 Table 6
21 Table 6
22 4 digits
23 4 digits
24 4 digits
25 4 digits
26 4 digits
27 4 digits
28-2F
30 2 digits
31 2 digits
32 2 digits
33 2 digits
34 4 digits
35 4 digits
36-3F
40 Table 7
1 Tables are numbered separately within this #UD section to be consistent with the Microsoft specification.
2 Notes refer to notes in the Microsoft specification
Version 1.0
Table 1 - AT#UD Last Call Status Report Format
required Definition
yes Diagnostic Command Specification revision number, digit.digit
0-A Call Setup Result code
0-1 Multi-media mode
0 DTE-DCE interface mode
yes V.8 CM octet string, same format as V.25ter Annex A, in quotes
yes V.8 JM octet string, same format as V.25ter Annex A, in quotes
Reserved for call negotiation reports
Note 4 2 Received signal power level, in –dBm (0-43)
Note 4 Transmit signal power level, in –dBm (0-17)
Note 4 Estimated noise level, in –dBm (10-90)
Note 4 Normalized Mean Squared error, 100 (0x64) = minimum inter-symbol
distance
Note 4 Near echo loss, in units of dB
Note 4 Far echo loss, in units of dB
Note 4 Far echo delay, in units of ms
Note 4 Round Trip delay, in units of ms
Note 4 V.34 INFO bit map
Reserved for modulation setup and training reports (Note 5)
Note 6 Transmit Carrier Negotiation Result
Note 6 Receive Carrier Negotiation Result
0-1F40 Transmit Carrier symbol rate (0-8000)
0-1F40 Receive Carrier symbol rate (0-8000)
0-FA0 Transmit Carrier frequency (0-4000)
0-FA0 Receive Carrier frequency (0-4000)
0-FA00 Initial transmit carrier data rate (0-64000)
0-FA00 Initial receive carrier data rate (0-64000)
Reserved
0-FF Temporary carrier loss event count
0-FF Carrier Rate re-negotiation event count
0-FF Carrier Retrains requested
0-FF Carrier Retrain requests granted
0-FA00 Final transmit carrier rate
0-FA00 Final receive carrier rate
Reserved
0-2 Protocol Negotiation Result (Note 7)
