- Page 1 CellPipe ™ IAD 4A and CellPipe ™ IAD 8T Hardware Installation Guide Part Number: 7820-0791-001 For software version 2.0 January 2001...
- Page 2 This material is protected by the copyright laws of the United States and other countries. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to Lucent Technologies), except in accordance with applicable agreements, contracts, or licensing, without the express written consent of Lucent Technologies.
-
Page 3: Trademarks
PacketStar, PathStar, Pinnacle, Pipeline, PMVision, PortMaster, SecureConnect, Selectools, Series56, SmoothConnect, Stinger, SYSTIMAX, True Access, WaveLAN, WaveMANAGER, WaveMODEM, WebXtend, and Where Network Solutions Never End are trademarks of Lucent Technologies Inc. Advantage Pak, Advantage Services, AnyMedia, ...Beyond Compare, End to End Solutions, Inter.NetWorking, MAXENT, and NetWork Knowledge Solutions are service marks of Lucent Technologies Inc. - Page 4 The eSight™ Service Center at http://www.esight.com provides access to technical support. You can obtain technical assistance through email or the Internet, or by telephone. If you need to contact Lucent Technologies for assistance, make sure that you have the following information available: •...
-
Page 5: Important Safety Instructions
Use an outlet tester or a voltmeter to check the ac receptacle for the presence of earth ground. If the receptacle is not properly grounded, the CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... - Page 6 17 A rare phenomenon can create a voltage potential between the earth grounds of two or more buildings. If products installed in separate buildings are interconnected, the voltage potential might cause a hazardous condition. Consult CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide...
- Page 7 être d'un calibre minimum de 26 AWG (American Wire Gauge), c'est-à-dire d'un minimum de 0,13 mm². Warnung: Um Feuer-Risiko zu reduzieren, müsssen die Querschnitte der Kommunikationskabel-Leiter 0,13 mm² oder größer sein. CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide...
-
Page 9: Table Of Contents
Power supply ......................4 CellPipe IAD 4A ............... 5 Connecting a CellPipe IAD 4A unit ................5 Checking the activity of CellPipe IAD 4A status lights ..........6 Configuring a CellPipe IAD 4A unit ................. 8 CellPipe IAD 8T ............... 9 Connecting a CellPipe IAD 8T unit ................ - Page 10 10/100 LAN connector pinouts ................15 T1 Connector pinouts ....................16 ADSL connector pinouts ..................16 FCC Regulations ..............17 FCC Part 15 Notice ....................17 IC CS-03 Notice ...................... 18 CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide...
-
Page 11: Introduction
Power supply ............4 New CellPipe products The CellPipe IAD 4A and CellPipe IAD 8T are now part of the CellPipe™ product line that run the IAD (Integrated Access Device) v. 2.0 software. These are integrated access devices supporting both voice and data communications. -
Page 12: Lucent Turn-Up
Lucent TURN-UP Lucent TURN-UP The CellPipe IAD 4A and CellPipe IAD 8T units support the Lucent TURN-UP automated provisioning system. TURN-Up is enabled when a user powers up his unit, which is then automatically configured via the configuration server located at his Internet Service Provider (ISP). -
Page 13: Preparing To Upgrade
You can locate the software binary file (or collection of software binary files) for the IAD CellPipes at ftp://ftp.ascend.com/pub/Software-Releases/CellPipe . CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... -
Page 14: Power Supply
Please check with your Sales Representative for the power supply and cables required for your environment. Refer to the illustrations below. Domestic power supply European power supply CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... -
Page 15: Cellpipe Iad 4A
Connecting a CellPipe IAD 4A unit........ -
Page 16: Checking The Activity Of Cellpipe Iad 4A Status Lights
Checking the activity of CellPipe IAD 4A status lights Observe the activity pattern of the lights on the front of the CellPipe IAD 4A unit to verify that the unit is connected properly. CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... - Page 17 The wan light blinks until a DSL connection is established, and then it remains • The con light is on only during the CellPipe IAD unit self-test and blinks when a voice port is offhook. CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide...
-
Page 18: Configuring A Cellpipe Iad 4A Unit
The unit disables Lucent TURN-UP to enable you to manually configure the unit. The Main menu items for the CellPipe IAD 4A unit are similar to those of other IAD CellPipe units. Refer to the CellPipe™ IAD User’s Guide for a discussion of the Main menu items. -
Page 19: Cellpipe Iad 8T
The CellPipe IAD box you receive contains the following items: CellPipe IAD unit 10BaseT Ethernet crossover cable (yellow) T1 WAN cable (blue) Power supply CellPipe™ IAD User’s Guide Hardware Installation Guide CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... -
Page 20: Checking The Activity Of Cellpipe Iad 8T Status Lights
Checking the activity of CellPipe IAD 8T status lights Observe the activity pattern of the lights on the front of the CellPipe IAD 8T unit to verify that the unit is connected properly. CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... - Page 21 The lan act light blinks during any LAN traffic. Otherwise, it remains off. • The wan lnk light blinks until a connection is established, and then it remains • The voice light is on only when a voice port is offhook. CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide...
-
Page 22: Configuring A Cellpipe Iad 8T Unit
Set the desired frame mode. Proceed with the remaining configurations. See Table 2. Table 2. T1 Configuration menu Menu option Description Select Frame Mode Choose between ESF (T1) Frame Mode or D4 Frame Mode. CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... - Page 23 Allows you to set the number of receive channels (maximum 24) for the WAN interface. Configure Clock Source Choose the Internal or External Clock Source. Change to E1 Mode Currently not supported. CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide...
-
Page 25: Connector Pinouts
Connector Pinouts TERMINAL pinouts Signal Tx Data Rx Data 10/100 LAN connector pinouts Signal CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... -
Page 26: T1 Connector Pinouts
Connector Pinouts T1 Connector pinouts T1 Connector pinouts Signal Rx Ring Rx Tip Tx Tip Tx Ring ADSL connector pinouts Signal Ring CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... -
Page 27: Fcc Regulations
The authority to operate this equipment is conditioned by the requirement that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Lucent Technologies. CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide... -
Page 28: Ic Cs-03 Notice
This precaution may be particularly important in rural areas. Warning: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate. CellPipe IAD 4A and CellPipe IAD 8T Hardware Installation Guide...
