CDM-740 Advanced Satellite Modem
Remote Control
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Management MGP 1 byte, value 0
Gateway Port or 1
Management MLC= 1 byte, value 0
Link thru 5
Configuration
Actual N/A None
Negotiated
Port Speed
N/A 3 bytes
Number of
Unread
stored
Events
Rx 1 Route to RD1= 1 byte, value 0
Default or 1
Gateway
Description of Arguments
Command or Query.
Selects which port management traffic should pass, where:
0 = WAN
1 = LAN
When the WAN port is seleted, all management traffic returns to the
WAN port.
When the LAN port is selected, all management traffic returns via the
LAN port and uses the Management IP Gateway as needed.
Example: MPR=1 (use LAN)
Command or Query.
Management Interface mode, where:
0=Auto Negoiate
1=1000Mbps -Full Duplex
2=100Mbps – Full Duplex
3=100Mbps – Half Duplex
4=10Mbps – Full Duplex
5=10Mbps – Half Duplex
Query only.
Returns actual negotiated port speed in the form abcd, where:
a is GE 1 negotiated port speed.
b is GE 2 negotiated port speed.
c is the management port negotiated port speed.
a, b, c, d have the following values:
0 = Link down
1=100 Full
2=100 Half
3=10 Full
4=10 Half
5=1000 Full
Query only.
Returns the Number of stored Events, which remain Unread (over
remote control) in the form xxx (0-255).
Example: NUE=126
Command or Query.
When enabled, all incoming Unicast traffic not destined to the CDM-740
local network subnet is directed to the configured default Gateway IP,
where:
0=Off (default)
1=on
Example: RD1=1 (pass traffic to the default gateway IP)
A–16
MN-CDM740
Query
Response to
(Instruction Response to Query
Command
& Qualifier)
MGP= MGP? MGP=x
MGP? (see Description of
MGP* Arguments)
MGP#
MLC = MLC ? MLC =x
MLC? (see Description of
MLC * Arguments)
MLC #
N/A NPS? NPS=abc
(see Description of
Arguments)
N/A NUE? NUE=xxx
(see Description of
Arguments)
RD1= RD1? RD1=x
RD1? (see Description of
RD1* Arguments)
RD1#
Revision 0
