- Page 1 LK-P12 Windows CE Printer Driver Manual LK-P12 Mobile Printer Rev. 1.00 Rev. 1.00 SEWOO TECH...
- Page 2 LK-P12 TABLE of CONTENTS Instruction. Supported processor family. How to install the Windows CE Printer Driver. How to setup the Windows CE Printer Driver. How to setup the printing dialog box with Windows CE Printer Driver. How to print with Windows CE Printer Driver.
-
Page 3: Supported Processor Family
LK-P12 1. Instrution. This Windows CE Printer Driver Manual explains how to install, how to setup and how to use mobile printer driver on OS like Microsoft Windows CE. The installation manual is written based on the LK-P11. The installation program is different. But, the installation procedure is same. -
Page 4: How To Install The Windows Ce Printer Driver
LK-P12 How to install the Windows CE Printer Driver. 2.1. Double-click the Driver installation file (LUKHANLK-P11WindowsCEPrinterDriver-xxx.exe). 2.2. Click the “Next>” button. 2.3. Click the “Next>” button. Rev. 1.00 SEWOO TECH... - Page 5 LK-P12 2.4. After confirming the license click the “Finish” button. 2.5. Choose the location to install and click the “Install” button. Rev. 1.00 SEWOO TECH...
- Page 6 LK-P12 2.6. You can see the progress of driver installation in PDA. 2.7. You can see the below message on PDA when the driver is successfully installed on your device. After seeing this message click the “ok” button. Rev. 1.00...
-
Page 7: How To Setup The Windows Ce Printer Driver
LK-P12 How to setup the Windows CE Printer Driver. Start Program Execute LK-P11 ARMV4(i) Setup.exe. The “Printer Commands” and “NV Upload” button are not available on below photo, because its basic emulation is CPCL. Click the “Port Settings” button. Input the port name what you want to use. - Page 8 LK-P12 COM5:115200 Click the “Add Port” button. You can see the added port in “Port Lists in Device”. Choose the port and click the “Select Port” button. Rev. 1.00 SEWOO TECH...
- Page 9 LK-P12 Click the “Paper Settings” button at Start Menu. Choose the paper you want to use. When the user does not choose the paper, the default paper set will be selected. Rev. 1.00 SEWOO TECH...
- Page 10 LK-P12 Choose the emulation according to your need. Value Description ESC/POS Receipt Printing. CPCL With Gap Label printing with gap. CPCL With Mark Label printing with Black Mark. CPCL Continuous Continuous label printing. When you choose ESC/POS emulation, you can use additional functions by clicking “Printer Commands”...
- Page 11 LK-P12 With this driver, you can print image and text which are stored in Flash of the printer. You only need to do input the number of stored logo. Click the “NV Upload” button to save the images to flash memory.
- Page 12 LK-P12 After connecting printer you can store data into the Flash of the printer and you can print and cancel it by adding files like below photo. When you finish the setting of printer driver, pleas click the “Save” button.
- Page 13 LK-P12 When you click “OK” button the program is closed. Restart the program and check it by using “Test Page Print”. Rev. 1.0 SEWOO TECH...
-
Page 14: How To Print With Windows Ce Printer Driver
LK-P12 How to setup printing dialog box with Windows CE printer driver. When you choose printing function in Windows CE printer driver, you can see the below printing dialog box. When you set up it like below picture and click “ ok” button, the printer starts printing.
