  • Page 1 MODEL : LK-P11B MOBILE PRINTER All specifications are subject to change without notice...
  • Page 2 RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTION...

  • Page 3: Table Of Contents

    Table of Contents 1. Product overview 2. Unpacking 3. Installation & Usage 3-1. Battery Installation 3-2. Battery Charging 3-3. Battery Charger Usage 3-4. Belt Strap Usage 3-5. Separation of Battery from the printer 3-6. Shoulder Strap Usage 3-7. Leather case Usage 3-8.

  • Page 4: Product Overview

    1. Product overview Power switch Paper feed Cover open button button Charger Connector Battery SERIAL...

  • Page 5: Unpacking

    2. Unpacking Standard Printer Battery Belt Buckle Recharger Serial Cable USB Shelded Cable Roll paper Quick Manual Option shoulder strap Battery Holder Cigar jack Printer case (Cradle)

  • Page 6: Installation & Usage

    3. Setting Up the Product 3-1. Installing battery Push the Open to the direction as pointed Open the battery cover and push up the hook to by arrow in the image. the direction as above. Insert the battery inside printer as shown. Close the battery cover once you inserted the battery completely.

  • Page 7: Battery Charging

    3-2. Battery Charging 1. The battery can be charged only when the temperature is 0~40 ℃ 2. Be sure that the printer is turn off and the battery to be charged is installed. 3. Connect the charger to the printer. 4.

  • Page 8: Battery Charger Usage

    3-3. Battery charger Usage ② ① 1. Please press the battery into the holder until you can hear a snapping sound . 2. Insert DC JACK into the end completely as the direct shown above. ① 3. Plug the power code to electrical outlet. 4.

  • Page 9: Belt Strap Usage

    3-3. Belt Hook Usage Insert the belt hook screw into the hole of the belt hook. As shown above, fasten the screw with a screw driver.

  • Page 10: Separation Of Battery From The Printer

    3-4. Removing battery Push the Open into the direction Push up the hook after opening the battery cover. indicated with the arrow in the image. Pull out the battery as shown above.

  • Page 11: Shoulder Strap Usage

    3-5. Shoulder Strap Usage Place the end of strap into the hook of Insert the strap into the hook on shoulder strap. the printer. After pulling out the end of strap Fasten the strap in the opposite side tightly, put it into the clip to be with the sample way.

  • Page 12: Leather Case Usage

    3-6. Leather Case Usage Put the printer into the leather case following the direction shown in the Open the Velcro image. Close the Velcro...

  • Page 13: Paper Installation

    3-7. Paper Installation Put the paper in the right direction after Open the paper cover pressing the adjusting the paper guide matching the open button. Insert a sharp tool into the paper guide hole and push it in the paper width. (Remove the paper core when it is used all) direction of arrow as shown above Pull out a short length of the paper...

  • Page 14: Control Panel Usage

    3-8. Control Panel Usage Button Name function This button is used to turn the printer on and off. Power When the printer is off, press this button for approximately 2 seconds and button it will turn on the power. When you press this button in a state that the printer is on, the printer will turn off.

  • Page 15: Self Test

    3-9. Self Test You can check the printer setting state by doing self test when you set the printer first time or encounter some problems. - Control Circuit, Mechanisms, Print Quality, Rom version. When you can not find the exact cause of problem through self test, investigate on other hardware parts or software.
  • Page 16 < Sample Printout of Self Test >...

  • Page 17: Peripherals Connection

    4. Peripherals Connection and cable. 4-1. Wifi(802.11b/g) Connection communication capacity (PDAs, PCs, etc.) 2. Use the connection function supported by the device to connect to the printer. Notes: Refer to the Manual for more details on connection.

  • Page 18: Interface Cable Connection

    4-2. Interface Cable Connection Serial 1. Connect the interface cable to the cable connector of the printer Notes: Use only cables provided by this manufacturer 2. Connect the interface cable to the USB or Serial port of the device (PDA, PC, etc)

  • Page 19: Printer Cleaning

    5. Printer cleaning If the interior of the printer is dusty, printing quality can lowered. In such a case, follow the instructions below to clean up the printer. NOTE 1. Make sure to turn the printer power off prior to cleaning 2.

  • Page 20: Product Specification

    6. Pritner Specification 6-1. Specification Printing Method Direct Thermal Printing Speed 80mm/sec Resolution 203 DPI X 203 DPI Character ALPHA NUMERIC Character, Extension Character Barcode Code 39, Code 93, UCC/EAN-128, Code 128, UPC-E, UPC-A, EAN-8, EAN-13, EAN-14, UPC and EAN 2 or 5 digit extensions, Plessey, FIM, Postnet, Interleaved 2-of-5, MSI, Codabar Emulation...
  • Page 21 Environmental sealing IP42 Temperature operation 5~40℃ storage -20~60℃ Humidity operation 35 ~ 80% storage 10 ~ 90%...

  • Page 22: Cpcl Command Compatibility

    7. CPCL Command Compatibility NOTE Compatible with only Partially commanders provided Compatible Compatible Compatible by the manufacturer. ○ △ ● Printer Commands Compatibility PRINT ○ FORM ○ JOURNAL ○ UNITS ○ Comments ○ TEXT Compatibility TEXT ○ FONT-GROUP(FG) ○ TEXT CONCATENATION ○...
  • Page 23 Graphics Compatibility ○ LINE ○ INVERSE-LINE ○ PATTERN ○ GRAPHICS ○ ○ Advanced Commands Compatibility CONTRAST ○ TONE ○ JUSTIFICATION ○ PAGE-WIDTH ○ PACE ○ NO-PACE ○ WAIT ○ REWIND TENSION SPEED ○ SETSP ○ ON-OUT-OF-PAPER ON-FEED ○ PREFEED ○ POSTFEED ○...
  • Page 24 Line Print Mode Compatibility SETLP ○ SETLF ○ Moving With X and Y Coordinates ○ LMARGIN ○ SETBOLD ○ SETSP ○ Special ASCII Characters ○ SETFF ○ SET-TOF ○ SETLP-TIMEOUT ○...
  • Page 25 SEWOO TECH CO.,LTD. Doosung BD, 689-20, Geumjeong-dong, Gunpo-si, Gyeonggi-do, 435-862, Korea TEL : +82-31-459-8200 FAX : +82-31-459-8880 www.miniprinter.com Rev. 1.0...
