5.
Blank Or No Display
Fault
No Display, blank (but green lit background)
display or flashing display
5.1
FLOW GRAPH
Cx Cx+ Troubleshooting Guide
Possible Solution
1. Cable From Main Board to Control Board
2. Control Board
3. Main Board
4. Control Board ID Chip
5. PSU
Page 14 of 17
