RGB DMX Deck Skirt
2.1M x 1M Starcloth
(order code: STAR25)
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RGB DMX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ledj RGB DMX

Summary of Contents for Ledj RGB DMX

  • Page 1 RGB DMX Deck Skirt 2.1M x 1M Starcloth (order code: STAR25) USER MANUAL...

  • Page 2: Safety Instructions

    LEDJ RGB DMX Deck Skirt Safety WARNING FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! CAUTION! Keep this equipment away from rain, moisture and liquids. SAFETY INSTRUCTIONS Every person involved with the installation, operation & maintenance of this...

  • Page 3: Operating Determinations

    LEDJ RGB DMX Deck Skirt Safety IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorised modification to the equipment. • Never let the power-cable come into contact with other cables. Handle the power-cable and all mains voltage connections with particular caution! •...

  • Page 4: Operating Modes

    LEDJ RGB DMX Deck Skirt Technical specifications Operating modes: 1, Stand Alone with Sound Activation 2, DMX operation For Sound Activation: With the power turned off set dip switch 10 to ON and all others to OFF. Turn on the power and the sensitivity control can now be set to the desired level.
  • Page 5 LEDJ RGB DMX Deck Skirt Technical specifications Channel DMX Number Function 240-249 Pattern number 24 Channel 1 250-255 (continued) Auto run through all programmes Animates the pattern selected on channel 1 0-255 Channel 2 (The higher the number the faster the speed)

  • Page 6: Dmx Control Mode

    LEDJ RGB DMX Deck Skirt DMX control mode DMX Control Mode Operating in a DMX control mode environment gives the user the greatest flexibility when it comes to customising or creating a show. In this mode you will be able to control each individual trait of the fixture and each fixture independently.
  • Page 7 LEDJ RGB DMX Deck Skirt DMX set up DMX-512: • DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent fixtures and controllers. A DMX controller sends DMX data instructions form the controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the DATA “IN”...
  • Page 8 LEDJ RGB DMX Deck Skirt DMX Set Up Notice: • Be sure to follow figures 2 & 3 when making your own cables. Do not connect the cable’s shield conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer casing.
  • Page 9 LEDJ RGB DMX Deck Skirt Dip Switch Reference Chart DMX Dip Switch Quick Reference Chart Dip Switch Position...

  • Page 10: Maintenance

    Maintenance Maintenance The RGB DMX Deck Skirt requires almost no maintenance. However, you should keep the unit clean, otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. The cloth will require monthly cleaning, as smoke-fluid tends to build up residues, reducing the light-output very quickly.
