  • Page 1 UPER ® UPER ERVER ® 6018R-MT 6018R-MTR Revision 1.0...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Manual

    MT/6018R-MTR. Installation and maintenance should be performed by experienced technicians only. The SuperServer 6018R-MT/6018R-MTR is a 1U rackmount server based on the SC813MFTQ-400CB/R400CB server chassis and the Super X10DRL-i serverboard. Please refer to our web site for updates on supported processors.
  • Page 4 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Chapter 4: Standardized Warning Statements You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 6018R-MT/6018R-MTR. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X10DRL-i serverboard, including the locations and functions of connectors, headers and jumpers.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SATA ......................1-2 PCI Expansion Slots ..................1-2 I/O Ports ......................1-2 Server Chassis Features ................1-3 System Power ....................
  • Page 7 Table of Contents Chapter 3 System Interface Overview ......................3-1 Control Panel Buttons ..................3-1 Reset ....................... 3-1 Power ......................3-1 Control Panel LEDs ..................3-2 Information LED ....................3-2 NIC2 ........................ 3-2 NIC1 ........................ 3-2 HDD ......................... 3-2 Power ......................3-3 Hard Drive Carrier LEDs .................
  • Page 8 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Installing a Passive CPU Heatsink ..............5-7 Removing the Heatsink ................... 5-7 Installing Memory Modules ................5-8 Installing & Removing DIMMs ................. 5-8 Memory Support for the X10DRL-i Serverboard ........5-9 Adding PCI Cards ..................5-10 Serverboard Details ..................5-11...
  • Page 9 Table of Contents VGA Enable/Disable ................. 5-21 Watch Dog ....................5-21 C Bus to PCI/PCI-Exp. Slots ..............5-21 ME Manufacturing Mode Select ............... 5-21 5-10 Onboard Indicators ..................5-22 LAN Port LEDs ..................5-22 Rear UID LED ..................5-22 Onboard Power LED ................5-22 BMC Heartbeat LED ................
  • Page 10 SUPERSERVER 6018R-MT/6018R-MTR User's Manual IPMI ....................... 7-36 Security Settings ................... 7-38 Boot Settings ....................7-39 Save & Exit ....................7-42 Appendix A BIOS Error Beep Codes Appendix B System Specifications...

  • Page 11: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 6018R-MT/6018R-MTR is comprised of two main subsystems: the SC813MFTQ-400CB/R400CB 1U chassis and the X10DRL-i serverboard. Please refer to our web site for information on operating systems that have been certified for use with the SuperServer 6018R-MT/6018R-MTR (www.supermicro.com).

  • Page 12: Serverboard Features

    ERVER 6018R-MT/6018R-MTR User's Manual Serverboard Features At the heart of the SuperServer 6018R-MT/6018R-MTR lies the X10DRL-i, a dual processor serverboard based on the Intel® PCH C612 chipset. Below are the main features of the X10DRL-i. See Figure 1-1 for a block diagram of the chipset.

  • Page 13: Server Chassis Features

    The following is a general outline of the main features of the SC813MFTQ-400CB/ R400CB chassis. System Power When configured as a SuperServer 6018R-MT, the SC813MFTQ-400CB chassis includes a single 440/480W power supply (p/n PWS-441P-1H). When configured as a SuperServer 6018R-MTR, the SC813MFTQ-R400CB chassis includes a re- dundant 400W power supply (p/n PWS-406P-1R).

  • Page 14: System Block Diagram

    UPER ERVER 6018R-MT/6018R-MTR User's Manual Figure 1-1. Intel C612 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. #2-4 #1-4 #2-3 #1-3 #2-2 #1-2 #2-1 #1-1 CPU1 CPU2 E5-2600(v3) E5-2600(v3) 9.6G SNB CORE SNB CORE DDR4 DDR4...

  • Page 15: Contacting Supermicro

    Chapter 1: Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
  • Page 16 UPER ERVER 6018R-MT/6018R-MTR User's Manual Notes...

  • Page 17: Chapter 2 Server Installation

    Preparing for Setup The box the SuperServer 6018R-MT/6018R-MTR was shipped in should include two sets of rail assemblies, six rail mounting brackets and the mounting screws you will need to install the system into the rack. Follow the steps in the order given to complete the installation process in a minimal amount of time.

  • Page 18: Warnings And Precautions

    UPER ERVER 6018R-MT/6018R-MTR User's Manual installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units.

  • Page 19: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 20: Installing The System Into A Rack

    ERVER 6018R-MT/6018R-MTR User's Manual Installing the System into a Rack This section provides information on installing the SuperServer 6018R-MT/6018R- MTR into a rack unit with the rack rails provided. If the server has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6.

  • Page 21: Installing The Rack Rails

    Figure 2-1. Installing Rear Inner Chassis Rails Installing the Rack Rails Determine where you want to place the SuperServer 6018R-MT/6018R-MTR in the rack (see Rack and Server Precautions in Section 2-4). Position the chassis rail guides at the desired location in the rack, keeping the sliding rail guide facing the inside of the rack.

  • Page 22: Installing The Server Into The Rack

    UPER ERVER 6018R-MT/6018R-MTR User's Manual Installing the Server into the Rack You should now have rails attached to both the chassis and the rack unit. The next step is to install the server into the rack. Do this by lining up the rear of the chassis rails with the front of the rack rails.

  • Page 23: Installing The Server Into A Telco Rack

    Chapter 2: Server Installation Installing the Server into a Telco Rack To install the SuperServer 6018R-MT/6018R-MTR into a Telco type rack, use two L-shaped brackets on either side of the chassis (four total). First, determine how far the server will extend out the front of the rack. Larger chassis should be posi- tioned to balance the weight between front and back.
  • Page 24 UPER ERVER 6018R-MT/6018R-MTR User's Manual Notes...

  • Page 25: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the hard drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specific components.

  • Page 26: Control Panel Leds

    UPER ERVER 6018R-MT/6018R-MTR User's Manual Control Panel LEDs The control panel located on the front of the SC813MFTQ-400CB/R400CB chassis has five LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 27: Power

    Chapter 3: System Interface Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Hard Drive Carrier LEDs Each drive carrier has two LEDs. • Green: When illuminated, the green LED on the drive carrier indicates drive activity.
  • Page 28 UPER ERVER 6018R-MT/6018R-MTR User's Manual Notes...

  • Page 29: About Standardized Warning Statements

    Chapter 4: Warning Statements for AC Systems Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 30 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 31 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 32: Installation Instructions

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 33: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 34: Power Disconnection Warning

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 35 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 36: Equipment Installation

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 37: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 38: Battery Handling

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬...
  • Page 39 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 40: Redundant Power Supplies

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 41: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 42: Comply With Local And National Electrical Codes

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬...

  • Page 43: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 44: Hot Swap Fan Warning

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 45 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 46: Power Cable And Ac Adapter

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only.
  • Page 47 Chapter 4: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué...
  • Page 48 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Notes 4-20...

  • Page 49: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the X10DRL-i serverboard into the SC813MFTQ-400CB/R400CB chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.

  • Page 50: Unpacking

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Unpacking The serverboard is shipped in antistatic packaging to avoid electrical static dis- charge. When unpacking the board, make sure the person handling it is static protected. Connecting Cables Now that the serverboard is installed, the next step is to connect the cables to the board.

  • Page 51: Rear I/O Ports

    Chapter 5: Advanced Serverboard Setup Figure 5-1. Control Panel Header Pins Ground 3.3 V FP PWRLED HDD LED UID Switch NIC1 Link LED NIC1 Activity LED NIC2 Activity LED NIC2 Link LED OH/Fan Fail/ UID LED PWR Fail LED) Power Fail LED 3.3V Reset Reset Button...

  • Page 52: Installing The Processor And Heatsink

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Installing the Processor and Heatsink Caution: When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: • Always connect the power cord last and always remove it before adding, re- moving or changing any hardware components.
  • Page 53 Chapter 5: Advanced Serverboard Setup 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push 4. Using your thumb and the index down to pop the load plate finger, remove the 'WARNING'...
  • Page 54 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Caution: You can only install the CPU to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't close properly, do not force it as it may damage your CPU. Instead, open the load plate again and double-check that the CPU is aligned properly.

  • Page 55: Installing A Passive Cpu Heatsink

    Chapter 5: Advanced Serverboard Setup Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the re- quired amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the serverboard and the heatsink bracket underneath.

  • Page 56: Installing Memory Modules

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Installing Memory Modules Note: Check the Supermicro web site for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMMs to prevent any possible damage. Installing & Removing DIMMs 1. Insert the desired number of DIMMs into the memory slots, starting with DIMM A1.

  • Page 57: Memory Support For The X10Drl-I Serverboard

    Chapter 5: Advanced Serverboard Setup Memory Support for the X10DRL-i Serverboard The X10DRL-i serverboard supports up to 512 GB of ECC LRDIMM (Load-Reduced DIMMs) or 256 GB of ECC RDIMM (registered DIMMs) DDR4-2133/1866/1600 memory in eight DIMM slots. Memory speed is dependent on the CPU. For the latest memory updates, please refer to our website a at http://www.supermicro.

  • Page 58: Adding Pci Cards

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Adding PCI Cards The 6018R-MT/6087R-MTR includes an RSC-RR1U-E8 riser card, which fits into a PCI-E slot to support a full-height half-length PCI Express expansion card. PCI Card Installation When installing a PCI add-on card, make sure you install it into a slot that supports the speed of the card.

  • Page 59: Serverboard Details

    Chapter 5: Advanced Serverboard Setup Serverboard Details Figure 5-5. X10DRL-i Layout USB0/1 COM1 JUIDB1 JPL1 USB12/13 LAN CTRL (3.0) LAN1 JPL2 LAN2 LEDM1 IPMI_LAN LAN CTRL X10DRL-i Rev. 1.01 CPU2 CLOSE 1st BIOS LICENSE BIOS OPEN 1st CLOSE 1st S-SATA3 S-SATA2 S-SATA1 S-SATA0...
  • Page 60 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Connector Description Onboard Battery COM1/COM2 Back Panel COM Port/Front Accessible COM Header Fan1-6, FanA/B CPU/System Fan Headers 24-pin ATX Main Power Connector Speaker/Power LED Front Panel Control Header JIPMB1 4-pin External BMC I C Header (for an IPMI Card)

  • Page 61: Connector Definitions

    Chapter 5: Advanced Serverboard Setup Connector Definitions ATX Power 24-pin Connector Pin Definitions Pin# Definition Pin # Definition ATX Power Connector +3.3V +3.3V The primary power supply connector -12V +3.3V (J24) on the X10DRL-i meets the SSI EPS 12V specification. Refer to the table PS_ON on the right for the pin definitions of this power connector.

  • Page 62: Power Fail Led

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Power Fail LED PWR Fail LED Pin Definitions The Power Fail LED connection is lo- Pin# Definition cated on pins 5 and 6 of JF1. Refer to 3.3V the table on the right for pin definitions.

  • Page 63: Power On Led

    Chapter 5: Advanced Serverboard Setup Power On LED Power LED The Power On LED connector is located Pin Definitions on pins 15 and 16 of JF1. This connec- Pin# Definition tion is used to provide LED indication of 3.3V power being supplied to the system. See PWR LED the table on the right for pin definitions.

  • Page 64: Universal Serial Bus (Usb)

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Universal Serial Bus (USB) Back Panel USB0/1 Pin Definitions (USB 2.0) Two USB 2.0 and two USB 3.0 ports are Pin# Definition Pin# Definition located on the rear I/O panel. A USB header (USB2/3) and a Type A USB con-...

  • Page 65: Sgpio Headers

    Chapter 5: Advanced Serverboard Setup SGPIO Headers SGPIO Headers Pin Definitions Three SGPIO (Serial General Purpose Pin# Definition Definition Input/Output) headers are included on the serverboard. These headers are Ground Data used to communicate with the System Load Ground Monitoring chip on the backplane and Clock No Connection provide a serial interface to the SATA...

  • Page 66: Lan1/2 (Ethernet Ports)

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual LAN Port Pin Definition Pin# Definition Pin# Definition Ground TD1+ LAN1/2 (Ethernet Ports) TD1- Two gigabit Ethernet ports (LAN1 and TD4+ Link 1000 LED LAN2) are located on the rear I/O panel. (Orange) These ports accept RJ45 type cables.

  • Page 67: Power Led/Speaker

    Chapter 5: Advanced Serverboard Setup PWR LED Connector Pin Definitions Power LED/Speaker Pin Setting Definition Pins 1-3 of JD1 are used for power Pin 1 JD1_PIN1 LED indication and pins 4-7 are for the Pin 2 FP_PWR_LED speaker. See the tables on the right Pin 3 FP_PWR_LED for pin definitions.

  • Page 68: Jumper Settings

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Jumper Settings Explanation of Jumpers To m o d i f y t h e o p e r a t i o n o f t h e serverboard, jumpers can be used to Connector Pins choose between optional settings.

  • Page 69: Lan1/Lan2 Enable/Disable

    Chapter 5: Advanced Serverboard Setup LAN1/LAN2 Enable/Disable LAN1/2 Enable/Disable Jumper Settings Change the setting of jumper JPL1 and Jumper Setting Definition JPL2 to enable or disable the LAN1 and Pins 1-2 Enabled LAN2 ports, repectively. The default set- Pins 2-3 Disabled ting is enabled.

  • Page 70: 5-10 Onboard Indicators

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual 5-10 Onboard Indicators Activity LED Link LED LAN Port LEDs The LAN1/2 and the dedicated IPMI Eth- LAN LED (Connection Speed Indicator) ernet ports all have two LEDs. One LED LED Color Definition indicates activity when blinking while...

  • Page 71: 5-11 Sata Ports

    Chapter 5: Advanced Serverboard Setup 5-11 SATA Ports SATA Port SATA 3.0 Ports Pin Definitions Ten SATA 3.0 ports are provided on Pin # Definition the serverboard. Six (I-SATA 0-5) are Ground supported by the Intel SCU in the PCH C612.

  • Page 72: 5-12 Installing Software

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual 5-12 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO file for your serverboard.

  • Page 73: Superdoctor® 5

    Chapter 5: Advanced Serverboard Setup SuperDoctor® 5 The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program moni- tors system health information such as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 74: 5-13 Onboard Battery

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual 5-13 Onboard Battery Please handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.

  • Page 75: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC813MFTQ chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 76: Control Panel

    UPER ERVER 6018R-MT/6018R-MTR User's Manual Figure 6-1. Chassis Front View Slim Optical or DVD Drive (optional) Control Panel Hard Drive Bays (4) System Reset Main Power Figure 6-2. Chassis Rear View Power Supply Modules* I/O Ports *The 6018R-MT includes a single power supply module only. Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system control buttons and...

  • Page 77: System Fans

    Chapter 6: Advanced Chassis Setup System Fans Four 4-cm high-performance fans provide the cooling for the SuperServer 6018R- MT/6018R-MTR. The chassis includes air seals under the fans and at the chassis cross section, which separates the drive bay area from the serverboard area of the chassis to promote better airflow.

  • Page 78: Sata Drive Installation

    UPER ERVER 6018R-MT/6018R-MTR User's Manual Accessing the Drive Bays SATA Drives: Because of their hot swap capability, you do not need to access the inside of the chassis or power down the system to install or replace SAS/SATA drives. Proceed to the next step for instructions. DVD-ROM Drive (optional): For installing/removing a DVD-ROM drive, you will need to gain access to the inside of the server by removing the top cover of the chassis.

  • Page 79: Sata Backplane

    Chapter 6: Advanced Chassis Setup Figure 6-4. Mounting a Drive in a Carrier SATA Backplane The SATA drives plug into a backplane that provides power, drive ID and bus termination. Figure 6-5. Removing a Drive from the Server...
  • Page 80 UPER ERVER 6018R-MT/6018R-MTR User's Manual DVD-ROM Drive Installation (Optional) The top cover of the chassis must be opened to gain full access to the DVD-ROM drive bay. The 6018R-MT/6018R-MTR accomodates only slim DVD-ROM drives. Side mounting brackets are needed to mount a slim DVD-ROM drive into the 6018R-MT/6018R-MTR server.

  • Page 81: Power Supply

    Chapter 6: Advanced Chassis Setup Power Supply 6018R-MT The SuperServer 6018R-MT has a single 440/480W power supply (PWS-441P-1H). This power supply has the capability of operating with an input voltage of 100-240V. Power Supply Failure If the power supply unit fails, the system will shut down and you will need to replace the power supply unit.

  • Page 82: 6018R-Mtr

    UPER ERVER 6018R-MT/6018R-MTR User's Manual 6018R-MTR The SuperServer 6018R-MTR has a 400 watt redundant power supply consisting of two power modules (PWS-406P-1R). Each power supply module has an auto- switching capability, which enables it to automatically sense and operate with an input voltage of 100-240V.

  • Page 83: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS setup utility for the X10DRL-i. The ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS setup utility screens. Note: For AMI BIOS recovery, please refer to the UEFI BIOS Recovery Instructions in Appendix C.

  • Page 84: How To Start The Setup Utility

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual How to Start the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS setup utility. From the main menu, you can access the other setup screens.
  • Page 85 Chapter 7: BIOS The following Main menu items will be displayed: System Date/System Time Use this option to change the system date and time. Highlight System Date or System Time using the arrow keys. Enter new values using the keyboard. Press the <Tab>...

  • Page 86: Advanced Setup Configurations

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Advanced Setup Configurations Use the arrow keys to select Advanced setup and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction.

  • Page 87: Power Configuration

    Chapter 7: BIOS Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. INT19 (Interrupt 19) Trap Response Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...

  • Page 88: Cpu Configuration

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual CPU Configuration  This submenu displays the following CPU information as detected by the BIOS. It also allows the user to configure CPU settings. Processor 1/Processor 2  This submenu displays the following information of the CPU installed in Socket 1 and Socket 2.
  • Page 89 Chapter 7: BIOS codes to overwhelm the processor to damage the system during an attack. This feature is used in conjunction with the items: "Clear MCA," "VMX," "Enable SMX," and "Lock Chipset" for Virtualization media support. The options are Enable and Disable.

  • Page 90: Advanced Power Management Configuration

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual DCA Prefetch Delay A DCA Prefetcher is used with a TOE (TCP/IP Offload Engine) adapter to prefetch data in order to shorten execution cycles and maximize data processing efficiency. Prefetching data too frequently can saturate the cache directory and delay neces- sary cache access.
  • Page 91 Chapter 7: BIOS  CPU P State Control (Available when Power Technology is set to Custom) EIST (P-states) EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically adjust processor voltage and core frequency to reduce power consumption and heat dissipation. The options are Disable and Enable. Turbo Mode Select Enabled to use the Turbo Mode to boost system performance.
  • Page 92 SUPERSERVER 6018R-MT/6018R-MTR User's Manual  CPU T State Control (Available when Power Technology is set to Custom) ACPI (Advanced Configuration Power Interface) T-States Select Enable to support CPU throttling by the operating system to reduce power consumption. The options are Enable and Disable.

  • Page 93: Chipset Configuration

    Chapter 7: BIOS than P0, with its frequency and voltage scaled back a notch. The options are Between P1/P0 and Below P1. Chipset Configuration Warning! Please set the correct settings for the items below. A wrong configuration setting may cause the system to become malfunction. North Bridge This feature allows the user to configure the settings for the Intel North Bridge.
  • Page 94 SUPERSERVER 6018R-MT/6018R-MTR User's Manual IOAT (Intel® IO Acceleration) Configuration Enable IOAT Select Enable to enable Intel I/OAT (I/O Acceleration Technology) support, which significantly reduces CPU overhead by leveraging CPU architectural improve- ments and freeing the system resource for other tasks. The options are Enable and Disable.
  • Page 95 Chapter 7: BIOS QPI (Quick Path Interconnect) Configuration QPI Status The following information will display: • Number of CPU • Number of IIO • Current QPI Link Speed • Current QPI Link Frequency • QPI Global MMIO Low Base/Limit • QPI Global MMIO High Base/Limit •...
  • Page 96 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Isoc Mode Select Enabled for Isochronous support to meet QoS (Quality of Service) require- ments. This feature is especially important for Virtualization Technology. The options are Enable and Disable. 7-14...

  • Page 97: Memory Configuration

    Chapter 7: BIOS Memory Configuration Enforce POR Select Enable to enforce POR restrictions on DDR4 frequency and voltage programming. The options are Enabled and Disabled. Memory Frequency Use this feature to set the maximum memory frequency for onboard memory modules. The options are Auto, 1333, 1400, 1600, 1800, 1867, 2000, 2133, 2200, 2400, 2600, 2667, and Reserved (Do not select Reserved).

  • Page 98: Dimm Information

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual A7 Mode Select Enabled to support the A7 (Addressing) mode to improve memory per- formance. The options are Enable and Disable. DIMM Information This item displays the status of a DIMM module specified by the user.

  • Page 99: South Bridge Configuration

    Chapter 7: BIOS Patrol Scrub Interval This feature allows you to decide how many hours the system should wait before the next complete patrol scrub is performed. Use the keyboard to enter a value from 0-24. The Default setting is 24. Demand Scrub Demand Scrubbing is a process that allows the CPU to correct correctable memory errors found on a memory module.
  • Page 100 SUPERSERVER 6018R-MT/6018R-MTR User's Manual USB Mass Storage Driver Support Select Enabled for USB mass storage device support. The options are Disabled and Enabled. Port 60/64 Emulation Select Enabled for I/O port 60h/64h emulation support, which in turn, will provide complete legacy USB keyboard support for the operating systems that do not support legacy USB devices.

  • Page 101: Sata Configuration

    Chapter 7: BIOS SATA Configuration  When this submenu is selected, AMI BIOS automatically detects the presence of the SATA devices that are supported by the Intel PCH chip and displays the fol- lowing items: SATA Controller This item enables or disables the onboard SATA controller supported by the Intel PCH chip.
  • Page 102 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Port 0 ~ Port 5 SATA Device Type Use this item to specify if the SATA port specified by the user should be con- nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.
  • Page 103 Chapter 7: BIOS Port 0 ~ Port 5 Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a SATA disk drive installed on this port without shutting down the system. The options are Enabled and Disabled. Port 0 ~ Port 5 Spin Up Device On an edge detect from 0 to 1, set this item to allow the PCH to start a COMRE- SET initialization to the device.
  • Page 104 SUPERSERVER 6018R-MT/6018R-MTR User's Manual • Software Preserve Support sSATA Port 0~ Port 3 Select Enabled to enable an sSATA port specified by the user. The options are Disabled and Enabled. sSATA Port 0 ~ Port 3 Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a sSATA disk drive installed on this port without shutting down the system.
  • Page 105 Chapter 7: BIOS sSATA RAID Option ROM/UEFI Driver Select EFI to load the EFI driver for system boot. Select Legacy to load a legacy driver for system boot. The options are Disabled, EFI, and Legacy. sSATA Port 0~ Port 3 This item displays the information detected on the installed sSATA drives on the particular sSATA port.
  • Page 106 SUPERSERVER 6018R-MT/6018R-MTR User's Manual • ME Firmware Status #2 • Current State • Error Code PCIe/PCI/PnP Configuration The following PCI information will be displayed: • PCI Bus Driver Version PCI Latency Timer Use this item to configure the PCI latency timer for a device installed on a PCI bus.
  • Page 107 Chapter 7: BIOS Maximum Payload Select Auto for the system BIOS to automatically set the maximum payload value for a PCI-E device to enhance system performance. The options are Auto, 128 Bytes, and 256 Bytes. Maximum Read Request Select Auto for the system BIOS to automatically set the maximum size for a read request for a PCI-E device to enhance system performance.

  • Page 108: Super Io Configuration

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual VGA Priority Use this item to select the graphics device to be used as the primary video display for system boot. The options are Onboard and Offboard. Network Stack Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Uni- fied Extensible Firmware Interface) for network stack support.

  • Page 109: Serial Port Console Redirection

    Chapter 7: BIOS Serial Port Console Redirection  COM 1 COM 1 Console Redirection Select Enabled to enable COM Port 1 Console Redirection, which will allow a client machine to be connected to a host machine at a remote site for networking. The options are Disabled and Enabled.
  • Page 110 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Stop Bits A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard serial data communication. Select 2 Stop Bits if slower devices are used. The options are 1 and 2.
  • Page 111 Chapter 7: BIOS SOL/COM2 Console Redirection Select Enabled to use the SOL port for Console Redirection. The options are Enabled and Disabled. *If the item above set to Enabled, the following items will become available for user's configuration: SOL/COM2 Console Redirection Settings Use this feature to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user.
  • Page 112 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start data-sending when the receiving buffer is empty.
  • Page 113 Chapter 7: BIOS *If the item above set to Enabled, the following items will become available for user's configuration: Out-of-Band Management Port The feature selects a serial port in a client server to be used by the Windows Emergency Management Services (EMS) to communicate with a remote host server.
  • Page 114 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Trusted Computing (Available when a TPM device is installed and detected by the BIOS) Configuration Security Device Support If this feature and the TPM jumper on the serverboard are both set to Enabled, onboard security devices will be enabled for TPM (Trusted Platform Module) sup- port to enhance data integrity and network security.

  • Page 115: Acpi Settings

    Chapter 7: BIOS ACPI Settings  WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) plat- form and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment to reduce system crashes and to enhance system recovery and health monitoring.

  • Page 116: Event Logs

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.

  • Page 117: View Smbios Event Log

    Chapter 7: BIOS Memory Correctable Error Threshold Use this item to enter the threshold value for correctable memory errors. The default setting is 10. Erasing Settings Erase Event Log Select Enabled to erase all error events in the SMBIOS (System Management BIOS) log before an event logging is initialized at bootup.

  • Page 118: Ipmi

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. IPMI Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status This item indicates the status of the IPMI firmware installed in your system.

  • Page 119: Bmc Network Configuration

    Chapter 7: BIOS When SEL is Full This feature allows the user to determine what the BIOS should do when the sys- tem event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately. Note: After making changes on a setting, be sure to reboot the system for the changes to take effect.

  • Page 120: Security Settings

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Security Settings This menu allows the user to configure the following security settings for the system. Password Check Select Setup for the system to prompt for a password at Setup. Select Always for the system to prompt for a password at bootup and upon entering the BIOS Setup utility.

  • Page 121: Boot Settings

    Chapter 7: BIOS Boot Settings Use this feature to configure Boot Settings: Boot Configuration Setup Prompt Timeout Use this item to indicate how many seconds the system shall wait for the BIOS setup activation key to respond before the system starts to boot. The default setting is 1. Boot Mode Select Use this item to select the type of device to be used for system boot.
  • Page 122 SUPERSERVER 6018R-MT/6018R-MTR User's Manual • Dual Boot Order #7 • Dual Boot Order #8 • Dual Boot Order #9 • Dual Boot Order #10 • Dual Boot Order #11 • Dual Boot Order #12 • Dual Boot Order #13 •...
  • Page 123 Chapter 7: BIOS  Network Drive BBS Priorities • Legacy Boot Order #1  UEFI Application Boot Priorities • UEFI Boot Order #1 7-41...

  • Page 124: Save & Exit

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 125 Chapter 7: BIOS Restore Defaults To set this feature, select Restore Defaults from the Exit menu and press <Enter>. These are manufacture default settings designed for maximum system performance but not for maximum stability. Save As User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <En- ter>.
  • Page 126 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Notes 7-44...

  • Page 127: Bios Error Beep Codes

    Appendix A: BIOS POST Error Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 128 SUPERSERVER 6018R-MT/6018R-MTR User's Manual Notes...

  • Page 129: System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Two Intel® E5-2600 (v3) Series processors in LGA2011 sockets (Socket R) Note: refer to our web site for details on supported processors and operating systems. Chipset Intel PCH C612 BIOS 128 MB SPI AMI BIOS SM Flash BIOS ®...

  • Page 130: System Cooling

    SUPERSERVER 6018R-MT/6018R-MTR User's Manual Chassis 6018R-MT: SC813MFTQ-400CB (1U Rackmount) 6018R-MTR: SC813MFTQ-R400CB (1U Rackmount) Dimensions (both): (WxHxD) 17.2 x 1.7 x 19.85 in. (437 x 43 x 504 mm) Weight 6018R-MT: Gross Weight: 36 lbs. (16.36kg.) 6018R-MTR: Gross Weight: 38 lbs. (17.27 kg.)

  • Page 131: Operating Environment

    Appendix B: System Specifications Operating Environment Operating Temperature: 10º to 35º C (50º to 95º F) Non-operating Temperature: -40º to 70º C (-40º to 158º F) Operating Relative Humidity: 20% to 95% (non-condensing) Non-operating Relative Humidity: 5 to 95% (non-condensing) Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3-3, CISPR 22 Class A...
  • Page 132 SUPERSERVER 6018R-MT/6018R-MTR User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

This manual is also suitable for:

Superserver 6018r-mtr

Table of Contents
