WaterLogic WL Cube Operating, Installation And Service Manual page 54

No Part No.
1 PL-1389
2 FW-0005-L00-00
3 FU-0012
4 PL-1391
5 PL-1390
6 PL-1395
7 PL-1392
8 PL-1393
9 ST-8350
10 PL-1387
11 PU-4008
12 PL-1311
13 ST-8207-CN
14 PU-4066
15 PU-4164
16 CT-2093
17 CO-9001-A
18 CO-9008
19 PL-1388
20 NA
21 EL-5029
22 NA
23 EL-5004
24 EL-5005
25 CO-9050
26 EL-5027
27 PL-1396
28 PL-1386
29 CT-2094
30, 31
NA
32 FU-0012
33 PL-1383
34 NA
35 FT-0008-L00-00
CUBE Operating, Installation, and Service Manual
Description
Left Side Panel
Spout, Mirror, No Gauze – 18 mm
UVC Sensor Fixing Metal Bracket
Front Frame Panel
Front Cover
Spout Assembly Bracket with BioCote®
Drip Tray Body with BioCote®
Drip Tray Grill with BioCote®
Rubber Feet
Base Plate
Equal Elbow Connector ¼" JG (PI0308S)
Leak Detection Sensor Bracket
Leak Containment Tray Clip – Sensor 0.5 mm
Stem Elbow Connector ¼" * ¼" JG (PI220808S)
Solenoid Valve 24 DC (Single Spring Load)
Cold Tank 1.4 Liter
Compressor
Domestic Filter Dryer
Side Panel – Right
Bulkhead Fitting ¼" x ¼" (ST)
Socket for Plug Connection
AC Power Fuse Holder with Fuse
Red Power Switch
Green Heater / Compressor Switch
Cooling Wire Condenser
Micro Door Lock S/W Only
Micro Switch Cover
Back Panel
Fan Motor – DC 24V
Hot and Cold Tank Drain Valve (consists of P/N's CT-2031 Drain Body
Valve 5/16" and CT-2025 Drain Valve Cap 5/16" – ¼")
UCV Sensor Fixing Metal Bracket
Top Cover
5/16" – ¼" Reducing Straight Connector
Filter Bracket
WLUSA Part No.
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
PL-1311
12-3180
NA
NA
NA
10-2200
12-1001
NA
NA
19-1090
NA
10-3008
10-3009
NA
NA
NA
NA
NA
14-5011
NA
NA
NA
NA
Page 54 - Revision: 6-23-2015
