WL200
MANUAL
Waterlogic Commercial Products, LLC
11710 Stonegate Circle
Omaha, NE 68164
(800) 288-1891
www.waterlogicdealers.com
Tech Portal Website:
techportal.waterlogic.com
Waterlogic International, LTD – Global Headquarters Grenfell Road, Maidenhead, Berkshire, SL6 1HN,
United Kingdom

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WL200 Series and is the answer not in the manual?

Questions and answers

Related Manuals for WaterLogic WL200 Series

Summary of Contents for WaterLogic WL200 Series

  • Page 1 WL200 MANUAL Waterlogic Commercial Products, LLC 11710 Stonegate Circle Omaha, NE 68164 (800) 288-1891 www.waterlogicdealers.com Tech Portal Website: techportal.waterlogic.com Waterlogic International, LTD – Global Headquarters Grenfell Road, Maidenhead, Berkshire, SL6 1HN, United Kingdom...
  • Page 2 United States and other countries. Waterlogic reserves the right to change the specifications referred to in this literature at any time, without prior notice. Changes or modifications not expressly approved by Waterlogic could void the warranty and user’s authority to operate the equipment.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS USER GUIDE · Safety Alert Symbols ..............4 · Safety Precautions ..............4 · Features and Benefits .............. 6 · Certifications ................7 · Model Designations and General Specifications ..... 8 · Electrical and Shipping Specifications ........9 ·...

  • Page 4: Safety Alert Symbols

    The installation, maintenance, sanitizing and any repair must be performed by qualified persons trained by Waterlogic International or their approved distributors only. Do not remove any panel or cover to protect against electrical shock and exposure to UV radiation.
  • Page 5 CAUTION! USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for injury or damage caused by excessive water pressure. Input or feed pressure must be 40 psi to 60 psi. Be aware of any potential pressure surges caused by building/municipal pumping stations.

  • Page 6: Features And Benefits

    WL200 FEATURES AND BENEFITS Cold Water Waterlogic WL200 Water Treatment System comes standard with Cold Water Selection. High Volume Storage and Water Capacity Tower Model has 4 liters of Cold Water Capacity. Counter Top has 2 liters of Cold Water Capacity.

  • Page 7: Certifications

    Standard for Drinking Water Coolers. CSA C22.2 No. 120 CSA Standard for Refrigeration. BPA Free - Waterlogic tests for BPA and declares that all of its products are Bisphenol-A FREE and contain no harmful BPA plastics. Waterlogic is certified to ISO 9001:2015 – Quality Management Systems (certified by Intertek).

  • Page 8: Model Designations And General Specifications

    MODEL/PART DESIGNATIONS MODEL - BRAND NAME DESCRIPTION PART NUMBER Waterlogic WL200 Counter Top - Cold Water WL200 Counter Top F-6002-M-C-TT-CS-WLU 12-WL200CT Serial Number Prefix: 50 or HJ2C116CS Waterlogic WL200 Tower - Cold Water WL200 Tower F-6002-FS-C-TT-CS-WLU 12-WL200FS Serial Number Prefix: 29 or HJ1C116CS...

  • Page 9: Electrical And Shipping Specifications

    SHIPPING SPECIFICATIONS ITEM WL200 Counter Top WL200 Tower 13.5” x 14.5” x 17.75” (34cm x 37cm x 13.5” x 14.5 x 40.5” (34cm x 41cm x Width/Depth/Height 45cm) 103cm) Weight (dry) 42 pounds (19.5 kg) 58 pounds (26.5 kg) ELECTRICAL SPECIFICATIONS ELECTRICAL SUPPLY 120V/60Hz, 1PH 15 Amp Service...

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS Dispensing Button The above picture shows front LCD display and control panel for the Waterlogic WL200 Water Treatment System. For Cold Water: Press the Dispensing Button. WL200 Manual Page 10 - Revision: 4-29-2019...

  • Page 11: Warranty

    Waterlogic will, at its sole discretion, determine whether to correct the defect or replace the unit, free of charge to you. If Waterlogic determines that the unit should be returned for warranty service, Waterlogic will approve of return in writing and will issue a Return Authorization which you must obtain prior to shipping the product.
  • Page 12 WL200 Water Purification System. Failure to follow the instructions in this manual could result in death, serious personal injury, or severe property damage. Only trained and qualified technicians should attempt to install, maintain, or service Waterlogic Equipment. 1. Visually inspect all electrical and water connections for signs of wear or damage.

  • Page 13: Lg Compressor Upgrade

    LG COMPRESSOR UPGRADE *Parts List in this manual updated to reflect these changes. New LG Compressor 120V R134A 1/8HP CSB035LJCM with external start/run capacitor. New LG Compressor with External Start/Run Capacitor New LG CSB035 LJCM Compressor Repair/Replacement Parts for are not interchangeable with older/other compressors.

  • Page 14: Adjusting Cold Water Set Point

    ADJUSTING COLD SET POINT Cold Water Temperature – Factory Set Point is 41°F (5°C) and can be adjusted to 34°F - 54°F (1.1°C to 12.2°C) The cold set point can be adjusted by accessing the cold thermostat adjustment screw under the decal at the rear of the unit.

  • Page 15: Replacement Components (Consumables)

    *Filter Element PN FT-0055-WLT schedule. FT-0053-IL-WLT Replacement parts can be obtained from Waterlogic or an Authorized Waterlogic Dealer. See Parts Layouts, Drawings, and Lists for additional repair parts. Surface Cleaning Clean on a regular basis with damp lint free cloth. Never use harsh chemicals (alcohol or acid based) or abrasive agents on any part of the product to avoid damage.

  • Page 16: Countertop Drawings And Parts List

    WL200 COUNTER TOP DRAWINGS with PART NUMBERS Wetted Parts WL200 Manual Page 16 - Revision: 4-29-2019...
  • Page 17 10 units purchased Drip Tray Grill – Charcoal 12-8150 Recommend stocking 4 each per PL-1152 every 10 units purchased Drip Tray - Charcoal with Waterlogic Logo 12-8055 PL-1156 Recommend stocking 4 each per every 10 units purchased ScaleKleen 01-2076...
  • Page 18 Remaining of Parts Flat Top Cover - Charcoal with 12-8060 Texture PL-1249-CN Counter Top Only High Voltage Metal Cover (ETL- ST-0049- ST-0049- Certification) L00-00 L00-00 Counter Top Only Purchase 5/16” x ¼” Reducing Elbow John from John PU-4007 Guest P/N PI211008S Guest Leak Detection PCB EN-6111-A...
  • Page 19 2L UV Cold Tank Assembly 12-3110 CT-2060 Counter Top Only Faucet - Cold only PL-1012 Natural Faucet O-Ring – Silicon 19.1 10-2600 White CT-2007 Front Upper Drip Tray Insert 12-8050 PL-1146 Panel 12-8605 PCB Cover PL-1180-CN 12-8615 Main PCB EN-6086 Front Upper Insert Panel - PL-0084- Charcoal...
  • Page 20 Verify compressor in machine before ordering parts as the Compressor P/N CO-0020-L00-00 and 10-2200 (CO-0001A) and related parts are not interchangeable. CO-0020-L00-00 Compressor CO-0020- LG Compressor 120V R134A CO-0020- 34A.1 L00-00 CSB035LJCM L00-00 CO-0019- CO-0019- 34A.2 Compressor Capacitor L00-00 L00-00 ST-0216- ST-0216- 34A.3...
  • Page 21 Cold Tank Thermostat – 12-1101 CT-2016 included with Cold Tank Power Line Noise Filter, 10-4013 ElectroMagnetic Interference EL-5016 filter (EMI) Fuse Holder and Fuse 120V / EL-5053 EL-5053 15A with One Wire 34.1 10-3013 Fuse 120V / 15A EL-5010 Red Power and Compressor 12-5600 EL-5019-A Switch...

  • Page 22: Tower Drawings And Parts List

    WL200 TOWER DRAWINGS with PART NUMBERS Wetted Parts WL200 Manual Page 22 - Revision: 4-29-2019...
  • Page 23 Drip Tray Grill – Charcoal 12-8150 Recommend stocking 4 each per every 10 PL-1152 units purchased Drip Tray - Charcoal with Waterlogic Logo 12-8055 Recommend stocking 4 each per every 10 PL-1156 units purchased WL200 Manual Page 23 - Revision: 4-29-2019...
  • Page 24 ScaleKleen 01-2076 Recommend stocking 2 each per every 10 Shown units purchased Remaining of Parts Faucet Cold only PL-1012 10-2600 Natural Faucet O-Ring – Silicon White CT-2007 12-8050 Front Upper Drip Tray Insert Panel PL-1146 12-8605 PCB Cover PL-1180-CN 12-8615 PCB for Cold Water EN-6086 PL-0084-...
  • Page 25 Purchase 5/16” x ¼” Reducing Elbow John Guest from John PU-4007 P/N PI211008S Guest Purchase 1/4” Union Elbow John Guest P/N from John PU-4008 P10308S Guest Unit Control Rubber Feet 10-3083 ST-8167CN Tower Only Bottom Tray 12-8004 ST-8137 Tower Only 10-2200 Compressor (R134a 1/8HP) 120V/60Hz CO-9001-A...
  • Page 26 Bulkhead Union ¼” x ¼” John Guest P/N 10-3067 PU-4028-A PI1208S Wire Condenser Special 12-8102 CO-9027 Tower Only Order Silver Back Panel 12-8002 ST-8135 Tower Only Cold Tank Thermostat – included with 12-1101 CT-2016 Cold Tank Power Line Noise Filter, ElectroMagnetic 10-4013 EL-5016 Interference filter (EMI)
  • Page 27 33.1 10-3017 PCB Stand-off Pin EN-6059 Purchase JG LLD PE Tube - Blue O.D.1/4"John from John PU-4031 Guest P/N PE-08-BI-1000F-B Guest 10-3007 Power Cord – 120V EL-5001-B Shown WL200 Manual Page 27 - Revision: 4-29-2019...

  • Page 28: Flow Diagrams

    WL200 COUNTER TOP WATER FLOW DIAGRAM WL200 Manual Page 28 - Revision: 4-29-2019...
  • Page 29 WL200 TOWER WATER FLOW DIAGRAM Water In Solenoid Valve Condenser WL200 Manual Page 29 - Revision: 4-29-2019...

  • Page 30: Electrical Schematics

    WL200 COUNTER TOP ELECTRICAL DIAGRAM DANGER! HIGH VOLTAGE ELECTRICAL HAZARD. PCB (Printed Circuit Board) contains High Voltage. Only trained and qualified technicians should attempt live testing. WL200 Manual Page 30 - Revision: 4-29-2019...
  • Page 31 WL200 TOWER ELECTRICAL DIAGRAM DANGER! HIGH VOLTAGE ELECTRICAL HAZARD. PCB (Printed Circuit Board) contains High Voltage. Only trained and qualified technicians should attempt live testing. WL200 Manual Page 31 - Revision: 4-29-2019...

  • Page 32: Pre-Installation Procedures

    Users will clog the drain with paper clips, erasers, napkins, tea bags, gum, and various other intended items. Waterlogic recommends you establish a minimum of weekly visits to the machine for cleaning of the drip tray drain.
  • Page 33 3. Connect sanitizing cartridge to inlet water supply and connect to inlet bulkhead fitting on back of unit. Turn on water supply. 4. Connect power to WL200 Water Treatment System. DO NOT TURN ON RED POWER SWITCH AT THIS TIME O = OFF. Fill the Cold Circuit with Sanitizer 5.
  • Page 34 Flushing the Sanitizer from the Machine 10. Place a pitcher, catch basin, or other container under the faucet of the WL200 Water Treatment System. 11. Flush the Cold Tank. Run several gallons of water through the faucet by dispensing cold water to dilute and remove the sanitizer from the cold circuit.

  • Page 35: Countertop Draining Procedure

    WL200 COUNTER TOP DRAINING INSTRUCTIONS Drain the WL200 Water Treatment System for transportation. WARNING! STORE UNIT EMPTY. ALWAYS SANITIZE BEFORE REUSE. The unit must be completely drained and sealed before storing to avoid stagnation and reduce microbial growth). Turn off Water Supply and Bleed Water Pressure 1.

  • Page 36: Tower Draining Procedure

    WL200 TOWER DRAINING INSTRUCTIONS Draining Notes Drain the WL200 Water Treatment System for transportation. WARNING! STORE AND TRANSPORT UNIT EMPTY. ALWAYS SANITIZE BEFORE USE. The unit must be completely drained before storing to avoid stagnation and reduce microbiological contamination (potential bacterial growth). Always sanitize before use to eliminate any potential microbiological contaminates.

  • Page 37: Installation Instructions

    Pre-installation and sanitization procedures as prescribed in this manual must be performed before installing the WL200 Water Treatment System. Always install indoors and place the Waterlogic WL200 Water Treatment System on a firm, flat and stable surface. WL200 Manual...
  • Page 38 40-60 psi. Turn on the water supply and check for leaks. 2. Check to ensure that the Red Power Switch is off. O=OFF 3. Connect the power cord to the back of the Waterlogic WL200 Water Treatment System and to a 120 Volt supply.

  • Page 39: Power Troubleshooting

    Black Power Connector to the Properly connect. PCB is not properly connected Replace Main PCB Bad Front PCB Part Number: EN-6086 / Waterlogic P/N 12-8615. Defective Red Power / Replace Red Power / Compressor Switch Compressor Switch 2. Compressor Runs But Does Not Chill...
  • Page 40 3. Compressor is Not Running Possible Reason Solution Red Power and Compressor Turn Red Power and Compressor Switch on. Switch button on unit is in the I = ON off position Turn Red Power and Compressor Switch off. O = OFF.

  • Page 41: Dispense Troubleshooting

    DISPENSING TROUBLESHOOTING INDEX 1. Dispensing won't stop when not holding the Dispensing Button 2. Water does not dispense from unit 3. Steady Drip out of Faucet 4. Irregular / Intermittent Dispensing 5. Small amount of water periodically dispenses from faucet automatically 6.
  • Page 42 1. Dispensing Won’t Stop when Not Holding the Dispensing Button Possible Reason Solution The correct input water pressure is critical to the performance of the unit to allow solenoids to open. Check water pressure at the inlet bulkhead with a water pressure Too much water pressure.
  • Page 43 2. Water does not dispense from Unit Possible Reason Solution The correct input water pressure is critical to the performance of the unit to allow solenoids to open. Check water pressure at the inlet bulkhead with a water Too much water pressure. pressure gauge.
  • Page 44 3. Steady Drip Out of Faucet Possible Reason Solution Debris in Solenoid Inspect Solenoid for debris and clean out as needed. 4. Irregular / Intermittent Dispensing Possible Reason Solution Check water pressure at the inlet bulkhead with a water pressure gauge.
  • Page 45 6. Low Flow of Water – Rated Service Flow is 1.89 Liters (0.5 gallons) per Minute Possible Reason Solution Rated Flow Rate is 1.89 Liters (0.5 gallons) per Minute. Determine Flow of Water Check Flow Rate by dispensing into a container for one minute. Measure the amount of water that has been dispensed.
  • Page 46 Red Heater and Compressor Turn Red Heater and Compressor Switch on. Switch on unit is off. I = ON Turn power off; unplug the unit and visually inspect solenoid connections into the Display PCB. Verify the soldering points Loose connection(s) on the on connections are secure into the board.
  • Page 47 10. Run On – Water continues to dispense out of faucet after releasing the dispense button Reason “Run On” or “Carry On” is present in all Waterlogic pressure fed units without outlet solenoids. “Run On” is defined is the amount of water that continues to dispense out of the faucet after releasing the dispense button.

  • Page 48: Cold Water Troubleshooting

    Wait for cold tank to chill water to temperature prior to dispensing more cold water. Cold tank capacity is 4 liters for Tower and 2 liters for Counter A greater capacity of Waterlogic Water Systems is available. Top. Check continuity of thermostat with multimeter. Replace Cold Water Thermostat thermostat as required.
