USER MANUAL
Safety Information.............................................................................................3
Specifications...................................................................................................4
Main Power Connection.....................................................................................5
DMX-512 Connection.........................................................................................5
Main Control Menu..............................................................................................................6
DMX Profile.........................................................................................................................8
Rigging the Fixture............................................................................................9
Cleaning & Maintenance.....................................................................................................9
Parts List.............................................................................................................................9
Advertisement
Table of Contents
Related Manuals for Mega Lite IDOL-LITE P24
Summary of Contents for Mega Lite IDOL-LITE P24
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information…………………………………………………………..…………………….3 Specifications……………………………………………………………………………………...4 Main Power Connection………………………………………………………………………….5 DMX-512 Connection…………………………………………………………………...………..5 Main Control Menu......................6 DMX Profile.........................8 Rigging the Fixture………………………………………………………………………………..9 Cleaning & Maintenance.....................9 Parts List..........................9... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Technical Information Part Numbers 4260– Idol Lite P24 Mechanical Specifications 19” DMX Connectors: Neutrik 3 pin XLR NC3FX-HD IP 65 connectors in and out Thermal: Maximum ambient temperature 104° Maximum surface temperature 140° Fastening System: Single Mounting Yoke, Base Plate, Dual Quick Re lease mount (included) Display: Digital... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz Cable (USA) -
Page 6: Main Control Menu
Display Menu The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions. The following will explain each func- tion and its options. - Page 7 This function will give you access to the LED Dimming curves. Press Enter. Use Dimmer the ▲ or ▼ to select the LED dimming operational curve from 0 that will not have Mode a dimming time to 3 that will have the longest dimming time, press Enter to con- firm your setting.
-
Page 8: Dmx Profile
Idol-LiteP24 DMX Profile Idol-Lite P24 3 Channel Mode DMX Chanel Function Description Value LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 Idol-Lite P24 5 Channel Mode DMX Chanel Function Description... -
Page 9: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. -
Page 10: Warranty Information
Warranty Information Warranty Conditions -Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty. -LEDs are not guaranteed to match in color temperature or output. -It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
