USER MANUAL
Table of Contents
Safety Information..............................................................3
Specifications.................................................................... 4
Main Power Connection..................................................... 5
DMX-512 Connection......................................................... 5
Main Control Menu......................................................................... 6
DMX Profile.................................................................................... 9
Rigging the Fixture.............................................................10
Cleaning & Maintenance................................................................10
Parts List........................................................................................10
Advertisement
Table of Contents
Related Manuals for Mega Lite Tuff Baby P-84
Summary of Contents for Mega Lite Tuff Baby P-84
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information…………………………………………………..…3 Specifications………………………………………………………….. 4 Main Power Connection…………………………………………….. 5 DMX-512 Connection……………………………………………..5 Main Control Menu................. 6 DMX Profile..................9 Rigging the Fixture……………………………...…………………….10 Cleaning & Maintenance..............10 Parts List..................10... - Page 3 Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5.
- Page 4 Technical Information Part Numbers 4100– Tuff Baby P84 Mechanical Specifications 8.80” 6.25” DMX Connectors: Weather 3 pin XLR connectors in and out Thermal: Maximum ambient temperature 104° Maximum surface temperature 140° Fastening System: Double Mounting Yoke Display: Digital 5.75” Power connection: Weather Seal Screw type 8.80”...
-
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 90V to 240V from 50Hz to Cable (USA) - Page 6 Display Menu CONTROL BOARD The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions. The following will explain each func- tion and its options.
- Page 7 Fade This function allows you to select a preprogrammed fade sequences. Press Enter use the up/down keys to select de- sired fade program (15 options). Press Enter to set the desired sped use the up/down keys (15 options). Press Enter to confirm the settings.
-
Page 8: Dmx Profile
DMX Profile Tuff Baby P84 Mode A DMX Chanel Function Description Value LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 Tuff Baby P84 Mode P DMX Chanel Function Description Value Dimmer Dimmer Off to Full 0-255... -
Page 9: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained profes- sional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi- ence including but not limited to calculating working loads, material being used and periodic safety inspections. - Page 10 Warranty Information Warranty Conditions -Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty. -LEDs are not guaranteed to match in color temperature or output. -It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
Need help?
Do you have a question about the Tuff Baby P-84 and is the answer not in the manual?
Questions and answers
hello I had set my light to 255,10,251 but its not changing to pink i want
The Mega Lite Tuff Baby P-84 uses DMX channels to control individual LED color intensities. Channel 2 controls red, channel 3 controls green, and channel 4 controls blue.
The values 255 (red), 10 (green), and 251 (blue) do not produce pink. Pink typically requires high red and blue values with low green, but 10 for green is not low enough to balance the strong red and blue. The resulting color would be closer to a light purple or violet.
To achieve pink, try using values like 255 (red), 0 (green), and around 127–200 (blue).
