USER MANUAL
Safety Information.......................................................................................................... 3
Specifications.................................................................................................................... 4
Main Power Connection...............................................................................................5
DMX-512 Connection................................................................................................... 5
DMX Profile......................................................................................................................... 6
Main Control Menu.......................................................................................................... 7
Rigging the Fixture..........................................................................................................9
Cleaning & Maintenance................................................................................................9
Parts List.............................................................................................................................. 9
Advertisement
Table of Contents
Related Manuals for Mega Lite N-E Color FX18
Summary of Contents for Mega Lite N-E Color FX18
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information……………………………………………………………………………………………. 3 Specifications…………………………………………………………………………………………………….. 4 Main Power Connection…………………………………………………………………………………..5 DMX-512 Connection…………………………………………………………………...……………..5 DMX Profile......................... 6 Main Control Menu......................7 Rigging the Fixture…………………………………………………………………………………………….9 Cleaning & Maintenance....................9 Parts List..........................9... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Technical Information Part Numbers Fixture 4076-N-E Color FX18 Mechanical Specifications 39.5” DMX Connectors: XLR 3 pin in/out Power Connections: Power Con in/out Thermal: Maximum ambient temperature 114° C 3” Maximum surface temperature 140° C Display: Digital Fastening System: Fixture Packaged for Shipping Size: 39.5”... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 240V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 220V from 50Hz to 60Hz Cable (USA) -
Page 6: Dmx Profile
DMX Profile N-E Color FX18 Mode A DMX Chanel Function Description Value LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 N-E Color FX18 Mode P DMX Chanel Function Description Value... -
Page 7: Main Control Menu
Main Control Menu CONTROL BOARD The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions. The following will explain each function and its options. Menu Down Enter... - Page 8 Flash This function allows you to strobe the LED’s on the whole module in White color. Press Enter use the up/down keys to select desired flash settings. Press Enter to confirm the settings. Fade Scroll This function allows you to fade the LED’s on the whole module from one color to another. Press Enter use the up/down keys to select desired fade speed settings.
-
Page 9: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. -
Page 10: Warranty Information
Warranty Information Warranty Conditions • Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty. • LEDs are not guaranteed to match in color temperature or output. • It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
