- Page 3 Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 2. This equipment is designed to be used only with the following lamp: 1 MSR 575/2 2 MDS 575 3.NSK 575 3.
-
Page 4: Technical Features
Technical Features Part Numbers Fixture Lamp Flight Case 1010 - AXIS 500 L-MSR575/2 - Phillips MSR575/2 P-1010DUALCASE L-MSD575 –Phillips MSD 575 L-NSK575 Mechanical Specifications Pan: 540° Tilt: 270° DMX Connectors: 3-pin XLR connectors Reflector: Glass reflector with cold mirror coating 18.75”... -
Page 5: Dmx-512 Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: 110V 50/60hz Connection Cable (USA) Cable (EU) International Black... -
Page 6: Lamp Replacement
Lamp Replacement Caution! 1. Disconnect power before you begging. 2. Allow 15min for the unit and lamp to cool. 3. Do not touch lamps glass envelope with your fingers. If this happens clean with alco- hol / to remove oils. Lamp Placement Remove the screws X, Y, and Z for re-lamping To insert the lamp MSR 575/2, NSK575 or MSD 575. -
Page 7: Gobo Wheels
¡ ¢ ¡ £ ¤ ¥ ¦ ¦ ¢ § 1: Open Color Wheel 2 1: Open Color Wheel 1 2: Deep Red 2: Orange 3: Yellow 3: Blue 4: Magenta 4: Light Green 5: Green 5: Cyan 6: Red 6: Magenta 7: Blue 7: Yellow... - Page 8 Axis 500 DMX profile-version 1.0 DMX Channel Function Description Value Pan course 0-255 Tilt Tilt course 0-255 Pan Fine Pan fine 0-255 Tilt fine 0-255 Tilt Fine Max speed (tracking mode) Max to min speed (vector mode) 1-249 Speed Changes...
- Page 9 Prism gobo macro 5 160-167 Prism gobo macro 6 168-175 Prism gobo macro 7 176-183 Prism gobo macro 8 184-191 Prism gobo macro 9 192-199 Prism gobo macro 10 200-207 Prism Con’t Prism gobo macro 11 208-215 Prism gobo macro 12 216-223 Prism gobo macro 13 224-231...
- Page 10 0-85 15º Beam with focus cont far to near Focus / Zoom 86-170 18º Beam with focus cont far to near 171-255 22º Beam with focus cont far to near Shutter closed 0-31 Shutter open 32-63 Strobe slow to fast 64-95 Shutter open 96-127...
-
Page 11: Main Control Menu
Use the up/down keys to select the required DMX channel. Press Enter to confirm or Mode to exit and return to main menu. The display will flash if there is no DMX signal been received from the console. The Axis 500 uses 16 or 14 DMX channels Reverse Pan This function allows you to invert the Pan direction. -
Page 12: Demo Sequence
© Enter to run sequence Unit Reset This option enables the Axis 500 to index all functions and return to their standard positions. Press Enter to confirm or Mode to exit and return to main menu. Advance settings This function opens up another group of advance maintenance and important settings. It is recommended that advance setting... -
Page 13: Lamp Control
¦ ¢ " ¡ § Use the up / down keys to browse through the special funcions and select one by pressing Enter. Manual control Display options Fan speed Adjusting default Lamp control DMX values Pan/Tilt feedback Lamp DMX Control Temperature Default settings Manuel control... -
Page 14: Display Options
Display options This function allows you to set display intensity, reverse the display and turn the display on of off. Display intensity: with this function you can adjust the display-intensity from 20% to 100%. Use up/down Keys to select the level of display intensity and press Enter to confirm or Mode to cancel and return to menu. -
Page 15: Default Settings
Default settings Press Enter to reset all fixture personalities to the default values. Default setting are Reverse Pan: Off Display options: 100 Reverse Tilt: Off Display turn: Turn 16 bit resolution: On Feed back: On Lamp on automatically: Off Lamp Control: On Lamp sensor: On Fan Speed: Auto Display options: On... -
Page 16: Error Messages
Error Messages Heat error: This message appears if you try to switch the lamp on within 5 minutes after having turned off the lamp. The message will also appear if the lamp doesn’t ignite within 28 seconds. The unit will automatically try to ignite the lamp again when 5 minutes have passed. -
Page 17: Parts List
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by authorized dealers only In order to avoid hazards. Should you have further questions , please contact your dealer. Parts List LMSR575/2 Phillips MSR 575/2 P-1010case Dual Axis 500 Case LMSD575 Phillips MSD 575 P-1010PCB Main PCB Card LNSK575 NSK 575... - Page 18 Mega-Lite 5718 Kenwick St San Antonio, TX 78238 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
