Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information What Is Included Specifications Main Power Connection DMX-512 Control Deco Driver Info Size & Weight Cleaning & Maintenance Rigging the Fixture Warranty Customer Support... -
Page 2: Safety Information
An IP66 rating in this fixture indicates that dust particles can not enter the fixture. And there is protection against powerful water spray from entering the fixture from any direction. What is Included 1pc Deco Flex C 6pc Single Point Mounting Clips 1pc User Manual... -
Page 3: Specifications
Specifications Part Numbers Fixture 5050C– Deco Flex C Mechanical Specifications IP Rating: IP66 Fastening System: 6 Mounting Clips (included) Power Connection: 5 Conductor Cable Housing: Silicone type material (3 type) Housing Type: Mushroom Top Curving Type: Left & Right Curve (when light output is facing up) Length: 19’... -
Page 4: Main Power Connection
White Cable DMX-512 Control When using the Deco Flex C with Deco Drivers the fixture is intended to be used in Ch4 or Ch7 modes. The Deco Driver will be required to be set in Ch4 or Ch7 operating modes... -
Page 5: Size & Weight
Size & Weight Tube With End Cap 15mm 17mm 26mm 28mm 18mm 17mm 12mm 14mm 19’ Feet 10.5” Inches (Including Cable) / 19’ Feet 9.25” (Without Cable) Fixture Size 19’10.5" (605.79cm) X 17mm X 28mm" Fixture Packaged 15" X 15" X 1.5" Net Weight 4.2lb Gross Weight... -
Page 6: Cleaning & Maintenance
Cleaning and Maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installation and electronics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded. -
Page 7: Warranty
WARRANTY FOR PRODUCTS PURCHASED AFTER JANUARY 1, 2021 MEGA SYSTEMS INC (“MSI”) hereby warrants to the original purchaser/owner (“Customer”), MSI products to be free of manufacturing defects in material and workmanship, for the warranty periods as defined below from the original purchase invoice date. This warranty applies exclusively to new MSI branded and/or distributed products listed below, purchased from an MSI AUTHORIZED dealer/ reseller. -
Page 8: Customer Support
Customer Support MEGA-Lite has a customer support line to provide set up help and to answer any question should you encounter a problem. Please visit our website for any other related technical documents. For service related issues, please contact our service dept. Monday—Friday 9am to 6pm CST Voice: 210-684-2600 E-mail: service@megasystemsinc.com...
