Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information What’s Included Specifications Main Power Connection DMX Connection Wireless Controller Display Settings DMX Profile Gates Size And Weight Installation Warranty Customer Service... -
Page 2: Safety Information
Use secondary safety chain when hanging unit. Place on a secure floor setting. Do not open unit while it is on. Risk of electrical shock. Mechanical What is Included 1pc Haze 2 Engine fixture 1pc Seetronics SAC3FX to Nema 5-15 Power Cable 1pc 1pc User Manual... -
Page 3: Specifications
Specifications Part Numbers Fixture Item ID 2002=Haze 2 Engine CAS-2002-1-B Mechanical Specifications Housing: Sheet Metal Direction: Forward and Upwards gates Mounting System: Rubber feet for Floor Mounting Power Connection: Input: Seetronics SAC3MPX Panel Mount Cable: Seetronics SAC3FX to Nema 5/15... -
Page 4: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit must be earthed. (Electronically grounded) Replace fuse only with the specified type and rating. (F10AL250V) Cable USA Cable EU 110V 220V Black Brown Live White Light Blue Neutral Green Yellow / Green... -
Page 5: Display Settings
Display Control The control board on the fixture base is your interface to access and control all the functions on the unit. It’s LED display gives you a code view of the options and functions. The following will explain each function. Heat: Heater Warming Up ADDRESS: Press Enter to view the fixture start channel. -
Page 6: Dmx Profile
DMX Profile Haze 2 Engine DMX Profile 2 Ch Mode Function Description Value Init Volume No Function Volume from Low to Heavy 6-255 Fan Speed No Function 0-10 Fan Speed 11-255 Gates To Point Haze upwards open gate A and close gate B ®... -
Page 7: Size And Weight
Size and Weight 18.5” ® Menu Up Down Enter 9.5” Fixture Size: 18.5” X 6.36” X 9.5” Manual Engage Fixture Weight: 12lb 18662 Bandera Rd Helotes,TX 78023 F10 250V www.mega.lighting Fuse Packaged Size: 21.5” X 9” X 10.75” 100-120VAC 60Hz (Only) Made In China Packaged Weight: 14lb... -
Page 8: Installation
Installation Caution! 1. The Installation must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injuries, if you have doubts concerning the safety do not install. 3. Unit is to be 24 inches away from flammable materials. 4. -
Page 9: Warranty
General Terms & Conditions 1. All resellers must have approved and signed Reseller Application on file, including their respective state tax information and W-9. Applications are re-evaluated on a fiscal calendar year basis to assure business integrity and tax status. 2. -
Page 10: Customer Service
Monday - Friday 9am to 6pm CST (210)684-2600 Service@mega.lighting Manual Version Please visit www.mega.lighting for the most up-to-date manual version. Manual Version Date Fixture Software Notes 1/09/2024 1.0.0 ® MEGA LITE 18662 Bandera Rd Helotes, TX 78023 Phone (210)684-2600 / Fax (210)855-6279 www.mega.lighting / info@mega.lighting...
