USER MANUAL
Safety Information.............................................................................................3
Specifications...................................................................................................4
Viewing Angles................................................................................................5
Main Power Connection.....................................................................................6
DMX-512 Connection.........................................................................................6
Main Control Menu..............................................................................................................7
DMX Profile........................................................................................................................10
Rigging the Fixture...........................................................................................12
Cleaning & Maintenance....................................................................................................12
Parts List............................................................................................................................12
Advertisement
Table of Contents
Related Manuals for Mega Lite Drama Strip P840
Summary of Contents for Mega Lite Drama Strip P840
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information…………………………………………………………..…………………….3 Specifications……………………………………………………………………………………...4 Viewing Angles……………………………………………………………………………………5 Main Power Connection………………………………………………………………………….6 DMX-512 Connection…………………………………………………………………...………..6 Main Control Menu......................7 DMX Profile........................10 Rigging the Fixture……………………………………………………………………………….12 Cleaning & Maintenance....................12 Parts List..........................12... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Technical Information Technical Information Part Numbers Fixture 7040-Drama Strip P840 Mechanical Specifications 41.75” XLR 3 and 5 pin in/out DMX Connectors: Power Connections: Power Con type in/out Thermal: Maximum ambient temperature 114° C Maximum surface temperature 140° C Display: Digital... -
Page 5: Viewing Angles
Viewing Angles Low Profile Up Light Adjustable... -
Page 6: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 240V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 220V from 50Hz to 60Hz Cable (USA) -
Page 7: Main Control Menu
Main Control Menu CONTROL BOARD The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions. The following will explain each func- tion and its options. - Page 8 White Dimmer This function allows you to dim the white LED’s on the entire strip. Press Enter use the up/down keys to select desired dimmer settings. Press Enter to confirm the settings. (255 Steps) Amber Dimmer This function allows you to dim the amber LED’s on the entire strip. Press Enter use the up/down keys to select desired dimmer settings.
- Page 9 Sound Flash This function allows you to select the flash pattern that will triggered via audio. Press Enter use the up/down keys to se- lect desired dimmer settings. Press Enter to confirm the settings. Sound Sensor This function allows you to select the sensitivity of the audio sensor. Press Enter use the up/down keys to select desired dimmer settings.
-
Page 10: Dmx Profile
DMX Profile Drama Strip P840 Mode A DMX Chanel Function Description Value LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 LED Color White LED Intensity 0-255 LED Color Amber LED Intensity... - Page 11 Drama Strip P840 Mode D DMX Chanel Function Description Value LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 " " " " " " " " LED Color Red LED intensity...
-
Page 12: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. -
Page 13: Warranty Information
Warranty Information Warranty Conditions -Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty. -LEDs are not guaranteed to match in color temperature or output. -It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
