BETCO FOREMAN AS26B Operator's Manual And Parts List

26” automatic scrubber
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
E86015-00
™
FOREMAN AS26B
26" Automatic Scrubber
Operator's Manual
Parts Schematic
©2007 Betco Corporation. All Rights Reserved. 1001 Brown Avenue • Toledo, Ohio 43607-0127 • 888-GO-BETCO • www.betco.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FOREMAN AS26B and is the answer not in the manual?

Questions and answers

Related Manuals for BETCO FOREMAN AS26B

Summary of Contents for BETCO FOREMAN AS26B

  • Page 1 E86015-00 ™ FOREMAN AS26B 26” Automatic Scrubber Operator’s Manual Parts Schematic ©2007 Betco Corporation. All Rights Reserved. 1001 Brown Avenue • Toledo, Ohio 43607-0127 • 888-GO-BETCO • www.betco.com...
  • Page 2 Receiving the machine Identification plate Immediately check, when receiving the machine, that all the material indicated on delivery documents has been received and also that the machine has not been damaged in transit. If it has been damaged, this damage must be immediately reported to the shipper and also to our customer service department.

  • Page 3: Symbols Used On The Machine

    SYMBOLS USED ON THE MACHINE Cock symbol Used to indicate the cock opening solenoid valve switch Brush symbol Used to indicate the main/brush motor switch Battery charge level symbol. Aspiration motor symbol. Indicates the aspiration motor switch. Brake symbol. Indicates the hand brake engaged signal lamp. Used over the emergency brake lever. Squeegee lift/lower symbol.

  • Page 4: General Rules Of Security

    GENERAL RULES OF SECURITY The rules below have to be followed carefully in order to avoid damages to the operator and to the machine. Read the labels carefully on the machine. Do not cover them for any reason and replace them immediately if damaged The machine must be used exclusively by authorized staff that has been instructed for its use During the working of the machine, pay attention to other people and especially to the children Do not mix different detergents, avoiding harmful odours...

  • Page 5: Machine Preparation

    MACHINE PREPARATION 1. HANDLING OF THE PACKED MACHINE The machine is packed in a specific package provided on a pallet for the handling with fork trucks. Do not place more than two packages on top of each other. The total weight is : 187 kg, machines without traction The overall dimensions are: A : 1140 mm MAXIMA 50/450/500/452/502...

  • Page 6: Installation Of The Batteries Into The Machine

    MACHINE PREPARATION 3. INSTALLATION OF THE BATTERIES INTO THE MACHINE The batteries must be housed in the battery compartment below the recovery tank. They must be handled using special hoisting equipment with suitable grasping systems and designed to support the weight of the batteries. The batteries must also conform to the requirements given in CEI 21-5 standards.

  • Page 7: Connection Of The Battery Connector

    MACHINE PREPARATION 7. CONNECTION OF THE BATTERY CONNECTOR The battery connector (2) has to be connected to the connector of the machine (1) 8. BATTERIES’ INDICATOR (machines with traction) The batteries’ indicator is digital with 4 fixed positions and a blinking one. The numbers, which appear on the display, show the approximate charge level.
  • Page 8 MACHINE PREPARATION 11. ADJUSTMENT SQUEEGEE INCLINATION During working operation, the rear rubber has to work slightly tilted backwards and this equally in its whole length for about 5mm. Should it be necessary to increase the rubber bending in the central part, then tilt the squeegee body backwards and turn the adjuster (1) counterclockwise.

  • Page 9: Recovery Tank

    MACHINE PREPARATION 13. ASSEMBLY CYLINDRICAL BRUSHES 1. Brake the machine acting upon the lever (1) 2. Lift the brush base acting upon the lever (2) 3. Turn the key (1) into position “0” and take it of 4. Remove the lateral right splash guard (see DISASSEMBLY AND CLEANING OF THE BRUSH UNIT) ATTENTION! Use gloves for this operation in order to protect your hands 1.

  • Page 10: Setting For Work

    PERFORMANCE 1. SETTING FOR WORK 1. Set the machine up for operation. 2. Check that the parking brake is released (1). 3. Connect the connector to the batteries (2). 4. Turn the main switch key (3) a quarter turn clockwise. The battey led display immediately comes 5.

  • Page 11: Overflow Device

    PERFORMANCE 2. OVERFLOW DEVICE The machine is equipped with a float, which intervenes when the recovery tank is full causing the closure of the suction hose. In this case, it is necessary to proceed with the emptying of the recovery tank taking off the plug of the exhaust pipe.

  • Page 12: On Completion Of The Work

    ON COMPLETION OF THE WORK At the end of the work day, before performing any type of maintenance: Close cock (3). Raise base (1). Raise squeegee (2) Turn off brush switch 1). Turn off aspiration motor switch (2). Move the machine to the water disposal point. Turn key (3) to turn the machine off.

  • Page 13: Daily Maintenance

    DAILY MAINTENANCE 1. CLEANING RECOVERY TANK 1. Open the hood (1). 2. Remove the drain tube (2) from its seat. 3. Empty the tank through the drain tube by turning the knob a few turns and then pulling out the plug.
  • Page 14 DAILY MAINTENANCE 4. REPLACEMENT OF THE SQUEEGEE RUBBERS Check the squeegee rubber wear and if necessary, change them. To replace them: 1. Take off the suction hose from its coupling. 2. Take off the the pin from the stud bolt. 3.
  • Page 15 DAILY MAINTENANCE 3. Clean the hopper as under item 13, paragraph “ON COMPLETION OF THE WORK” 4. Make sure that, at the brushes ends nothing is coiled up like wires, plastic or anything else which does not allow the free brushes rotation. Otherwise: Unscrew the wing nut (1) Take off the plate (2) Remove the splash guard (3)

  • Page 16: Weekly Maintenance

    WEEKLY MAINTENANCE CLEANING OF THE SQUEEGEE HOSE Weekly or whenever suction seems to be unsatisfactory check that the squeegee hose is not obstructed. Eventually, clean it proceeding as follows: 5. Take off the hose from its coupling on the squeegee 6.

  • Page 17: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE 1. INSUFFICIENT WATER ON TO THE BRUSH 4. Check that the cock is open (signal lamp on). 5. Check that there is water in the solution tank. 2. MACHINE DOES NOT CLEAN WELL 6. Check the condition of the brushes and replace if necessary (brushes must be replaced when bristles are 15 mm.
  • Page 18 SMALTIMENTO ATTENZIONE: Il prodotto, giunto a fine vita, deve essere conferito ai punti di raccolta differenziata messi a disposizione dell'utente finale.
  • Page 19 CHOICE AND USE OF BRUSHES POLYPROPYLENE BRUSH (PPL) It is used on all types of floors which are hot water resistant (not more than 60 C). The Polypropylene brush is nonhygroscopic and therefore conserves its characteristics even if working in the wet conditions. NYLON BRUSH It is used on all types of floors with excellent wear and hot water resistance (more than 60 C).
  • Page 20 CE STATEMENT OF COMPLIANCE model Maxima 450/500/452/502/650/50 The undersigned company: FIMAP S.p.A. Via Invalidi del Lavoro n.1 37050 Santa Maria di Zevio (VR) states under its own exclusive responsibility that the product FLOOR SCRUBBING MACHINE model Maxima 450/500/452/502/650/50 complies with the provisions of Directives: 98/37/EEC: Machine directive.
  • Page 22 DESCRIPTION DESCRIPTION ITEM ITEM 213390 BRUSH BASE 1.32 E83700 Shaft Key 5x5x20mm E88015 Nut, Lock M20 1.33 E82774 Lock Washer, M6 Zinc E20253 Flat Washer M21x60x3 Nylon 1.34 E82772 Hex Bolt M6x20 Zinc E81657 Bearing, 6204 2RS 1.35 E83923 Bearing, 6004 2RS 210260 PULLEY 1.36 209860...
  • Page 24 ITEM DESCRIPTION ITEM DESCRIPTION E81737 Axle 415982 CARBON BRUSH MOTOR 414314 WHEEL 405975 SPLASH GUARD E86175 Support NUT M16x1,5 AUTOBL UNI 74 203541 SUPPORT WASHER M8 UNI 6592 E82529 Caster, Rear Abila NUT M8 AUTOBL. UNI 7474 414332 WHEEL SCREW M8x16 UNI 5933 E82395 Washer SCREW M8x18 UNI 5931 E82542 Drive Wheel 175 OD x 45...
  • Page 26 ITEM DESCRIPTION ITEM DESCRIPTION E82275 Pin, Adjustable Mounting M10 Zinc E83914 Hex Bolt M6x20 SS E82280 Pin, Fixed Mounting M10 Zinc E82253 Bushing, Brass E12666 Squeegee Vacuum Hose E83802 Hex Bolt M8x30 Zinc E81834 E82707 Set Screw Hex Soc Flat End M6x40 SS Squeegee Blade, Polyurethane E81835 Squeegee Blade, Polyurethane...
  • Page 28 ITEM DESCRIPTION ITEM DESCRIPTION 202176 TUBE E85762 Hose Clamp 416172 E85762 CLAMP Hose Clamp E81454 Barbed Elbow 202210 TUBE 203391 SUPPORT E81565 Clamp, 4.8x200 Black E82366 Valve E82393 Fitting, Tee 202188 202209 TUBE TUBE E88400 Fitting E86251 Nipple E86178 O-Ring E85760 Gromment E83118...
  • Page 30 ITEM DESCRIPTION 203491 E83932 Bushing E85767 Bushing E82309 Spring, 11.8x1.2x15mm 412449 203496 KNIFE 203495 STUD BOLT E82837 Spring E82837 Spring 203494 KNIFE 203493 TIE ROD 412450 RETURN 203492 HANDLE E81318 Knob E83832 Flat Washer M8.5x30x3 Nylon E81714 Spring WASHER M8 D.24 UNI 6593 SCREW M8X25 UNI 5739 WASHER M8 DIN 6798/A SCREW M8X40 UNI 5739...
  • Page 31 Recovery Drain Hose Solution Drain Hose...
  • Page 32 ITEM DESCRIPTION ITEM DESCRIPTION E83850 Flat Washer M5x20 SS E81710 Hose Clamp 415147 E88384 COVER Fitting, Recovery Tank Hose 415148 COVER E82790 Air Filter/Shutoff 415144 PANEL E88102 Recovery Filter Assembly E86195 Cover, Bonnet Gray E81786 Hose Clip E88125 Bushing E86290 Drain Hose 202887 E88126...
  • Page 34 ITEM DESCRIPTION ITEM DESCRIPTION 203511 COVER 414545 CABLE E82493 Grips, Handle E83584 Battery jumper cable 415140 PIPE E86208 SB50 Red Electrical Connector E81019 O-Ring E86208 SB50 Red Electrical Connector E82782 Washer SCREW Ø 4,8X32 UNI 6954 E85751 Trigger Lever NUT M5 UNI 5588 E81625 Shank, M5x32 SCREW M3X20 UNI 5739 A2...
  • Page 36 ITEM DESCRIPTION ITEM DESCRIPTION 415152 203526 PROTECTION PANNEL E83168 Fuse, 3 amp E83495 Hour Meter E88244 Fuse Holder E83315 Switch Key 409869 PLATE SCREW M4X10 UNI7687 E86196 Fuse, 60 amp WASHER M4 D.12 UNI 6593 E83926 Fuse 30A faston suction motor NUT M4 UNI 7474 E81642 Fuseholder...
  • Page 38 DESCRIPTION ITEM E81477 Knob 25X50 M8 203506 HANDLE E82550 Handle - Lever S42 414726 BUSHING 203497 LEVER E85768 Squeegee Cable E81907 203505 SHAFT 202458 SPACER 415138 CABLE E86154 Fork 415154 CABLE E86154 Fork 203499 BRACKET 409392 NUT M6 UNI 7474 SCREW M6X16 UNI 5739 SCREW M6X30 UNI 5739 WASHER M6 DIN 6798/A...
  • Page 40 ITEM DESCRIPTION 202243 DEADENING HOSE E83920 Clamp 9x300 4,8x360 black E83949 Motor, Vacuum E82631 Motor, Vacuum 36v 720w 2-Stage 414960 SUPPORT E83944 Sound Deadening Foam 415134 STUD BOLT E87975 Stud Bolt Tripla 414686 SPACER E83244 deadening hose E83871 Compression spring 55x2x200 414350 DEADENING HOSE 203523...
  • Page 42 ITEM DESCRIPTION E83328 Vacuum switch E83316 Key Switch E88022 Battery Check Card 24 Volt E83328 Vacuum switch E81706 Signal Lamp Green E83164 Micro Switch 409448 POTENTIOMETER 2K E82270 Micro Switch E82270 Micro Switch E83628 Contactor 24VDC E83160 Relay 24VDC 30A E83664 Insulator WS17 E83168...
  • Page 44 Service Distributor. If the original part is returned within the warranty policy period from date of delivery for inspection by Betco and is found to be defective the owner will be credited for the cost of replacement parts plus shipping and handling.
