- Page 1 MPC 21” Series 21” Multifunctional Touch Panel PC Quick Reference Guide Ed – 28 october 2010 Part No. E201721W3A1R...
-
Page 2: Getting Started
MPC 21” Series 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. -
Page 3: System Specifications
Quick Reference Guide 1.3 System Specifications Panel MPC-21W3 MPC-21W5 Model 21.6”, 16:9 LCD size Display type Full HD Resolution 1920 x 1080 Color 16.7M Pixel pitch 0.248mm(H) x 0.248mm(V) 300 cd/m² Luminance 1000 Contrast ratio Viewing angle 80(U), 80(D), 85(L), 85(R) - Page 4 MPC 21” Series External I/O Ports COM Port 1 x RS-232/422/485 setting by BIOS*, optional extra 1 x RS-232/422/485 2 x RJ-45 1 x RJ-45 Ethernet Port 1 x DB-15 VGA / LCD Port Line-out Line-out Audio Port USB Port 2 x USB 2.0 Power Supply Unit Power Input...
-
Page 5: System Overview
2 x USB 2.0 connector Dock USB RJ-45 Ethernet connector 1 LAN1 LAN2 RJ-45 Ethernet connector 2 (KB/MS) (LAN2 is default for MPC-21W3, KB/MS is default for MPC-21W5) HDD indicator System power indicator CRT connector DB-15 female connector RESET Reset button... -
Page 6: System Dimensions
MPC 21” Series 1.5 System Dimensions 6 MPC 21W Series Quick Reference Guide... - Page 7 Quick Reference Guide 2. Hardware Configuration Note: If you need more information, please visit our website: http://www.avalue.com.tw MPC 21W Series Quick Reference Guide...
-
Page 8: Bios Settings
MPC 21” Series 2.1 BIOS settings 2.1.1 MPC-21W3 RS232/422/485 setting by BIOS The COM port setting of MPC-21W3, which applies for EBM-945GSE M/B, can be configured by BIOS; the path is shown as below. [BIOS Menu] [Integrated Peripherals] [Super IO Device]... - Page 9 Quick Reference Guide 2.1.2 MPC-21W5 backlight control setting by BIOS The Backlight control setting for MPC-21W5, which applies for EBM-PNV M/B, can be configured by BIOS; the path is shown as below. [Chipset] [North Bridge Configuration] [Video Function Configuration] Panel 2 Back light mode: PWM mode Panel 2 Back light control: 100% Note: Panel 1 Back light mode : DC mode...
-
Page 10: Installing Hard Disk & Memory
MPC 21” Series 2.2 Installing Hard Disk & Memory Step 1. Memory Installation: Unfasten 6 screws from the case to take off the top chassis. Step 2. Insert the SODIMM into the memory socket. Step 3-1. HDD Installation: Unfasten 2 screws of the HDD bracket and take it off. 10 MPC 21W Series Quick Reference Guide... - Page 11 Quick Reference Guide Step 3-2. Insert the HDD into the bracket and fasten 4 screws. Step 3-3. Insert the cable to connect HDD and SATA connectors. SATA Connector IDE Connector Step 3-4. SATA HDD Installation: By default, SATA cables had been inserted to respective connectors.
- Page 12 MPC 21” Series Step 3-5. Insert the HDD back and fasten 2 screws. Step 4. Place back the chassis with 6 screws locked. 12 MPC 21W Series Quick Reference Guide...
