- Page 1 MPC-21W7 21" FHD Fanless Digital Signage Panel Computer with ATOM Dual Core Solution Quick Reference Guide Ed – 24 April 2013 Part No. E201721W7A0R...
-
Page 2: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x MPC-21W7 21" FHD Fanless Digital Signage Panel Computer with ATOM Dual Core Solution 1 x Quick Reference Guide ... -
Page 3: System Specifications
Serial Port Ethernet 1 x RJ-45 1 x HDMI Audio port Line out 2 x USB 2.0 Speaker 2 x 1W Mouse & K/B 1 x PS/2 KB & MS Display Chipset Intel NM10 Express Chipset MPC-21W7 Quick Reference Guide... - Page 4 32 to 122°F (0 to 50°C) Storage Temp. -4 to 167°F (-20 to 75°C) Operating Humidity 5%~90% relative humidity, non-condensing Dimensions 508.2 x 301.3 x 53.1 mm Weight 6 Kgs / 6.69 Kgs (with Touch) 4 MPC-21W7 Quick Reference Guide...
-
Page 5: System Overview
Keyboard-Mouse connector DC-IN DC power-in connector VGA/HDMI CRT connector/HDMI connector Reset Reset button USB connector RJ-45 Ethernet connector 1 LAN1 LINE OUT Line-out audio jack HDD indicator System power indicator Compact Flash/ Compact Flash card connector COM2 MPC-21W7 Quick Reference Guide... - Page 6 MPC-21W7 1.5 System Dimensions (Unit: mm) 6 MPC-21W7 Quick Reference Guide...
- Page 7 Quick Reference Guide 2. Hardware Configuration Note: If you need more information, please visit our website: http://www.avalue.com.tw MPC-21W7 Quick Reference Guide...
- Page 8 2.1 Installing HDD & MPCIE Step 1. Unfasten 6 screws from the case. Then take off the top chassis. Step 2.1. Insert the SODIMM into the memory socket. Step 2.2. Remove 2 screws to release the HDD bracket. 8 MPC-21W7 Quick Reference Guide...
- Page 9 Quick Reference Guide Step 3. Secure HDD by means of 4 screws. Step 4. Insert the HDD into the Drive Bay. Remember to place the HDD down to the bottom exactly in order to screw the device tightly. MPC-21W7 Quick Reference Guide...
