- Page 1 MARINE PC MARINE PC MPC-OPC12 & -15 12.1” & 15” LED/LCD Touch Screen Panel PC Fanless Intel® CoreTM E3845 QuadCore CPU Rugged Embedded Computer for All-Weather Conditions Quick Reference Guide Ed –4 December 2018 Copyright Notice Copyright 2018 Marine PC...
- Page 2 These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. To receive the latest version of the user’s manual; please visit our Web site at: http://www.marinepc.com 2 MPC-OPC12/15 Quick Reference Guide...
-
Page 3: Table Of Contents
1.3 System Specifications ....................5 1.4 System Overview ....................7 1.4.1 I/O View ..........................7 1.5 System Dimensions ....................8 1.5.1 MPC-OPC12 ......................... 8 1.5.2 MPC-OPC15 ......................... 8 BIOS SETUP......................10 2.1 Introduction......................11 2.2 Starting Setup......................11 2.3 Using Setup...................... -
Page 4: Getting Started
1.2 Packing List 1 x MPC-OPC12/15 Panel PC 1 x Power Adapter (if ordered) 1 x Power cord (for DC cord, White is +, Black is -) -
Page 5: System Specifications
1 x RS-232/422/485 (Factory Optional) Com Port 1 x RS-232 Other 3 x Knockouts for Antenna Mounting Display Intel® Valleyview SoC integrated Graphics Chipset Supports optional dual display Resolution HDMI: Max. resolution 1920x1200 @ 60Hz (by IET module) MPC-OPC12/15 Quick Reference Guide... - Page 6 With SSD/mSATA : 3Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis Operating with SSD/CFast/mSATA : MIL-STD-810G, Method 516.6, Shock Test Procedure I, functional shock=20G Certifications CE, FCC Class B OS Information Win 10, Linux Ordering Information/ Description ACC-ARC-USB-1R 4 x USB3.0 (ARC-BYT DB-A) MPC-OPC12/15 Quick Reference Guide...
-
Page 7: System Overview
DC Power-in connector Option: Phoenix Connector(MOQ apply) COM1/2 Serial port 1/2 connector DB-9 male connector 3 x USB 2.0 connector 1 x USB 3.0 connector LAN1/2 RJ-45 Ethernet 1/2 HDD/Power LED indicator Power Switch Power on button MPC-OPC12/15 Quick Reference Guide... -
Page 8: System Dimensions
1.5 System Dimensions 1.5.1 MPC-OPC12 (Unit: mm) MPC-OPC12/15 Quick Reference Guide... -
Page 9: Mpc-Opc15
1.5.2 MPC-OPC15 (Unit: mm) MPC-OPC12/15 Quick Reference Guide... -
Page 10: Bios Setup
2.BIOS Setup 10 MPC-OPC12/15 Quick Reference Guide... -
Page 11: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP MPC-OPC12/15 Quick Reference Guide 11... -
Page 12: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “ ” pointer marks all sub menus. 12 MPC-OPC12/15 Quick Reference Guide... -
Page 13: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. MPC-OPC12/15 Quick Reference Guide... -
Page 14: Bios Setup
<Enter> to accept and enter the sub-menu. 2.6.1 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 14 MPC-OPC12/15 Quick Reference Guide...
