- Page 1 MPC-42W7 42" Full HD Fanless Multi Media Touch Panel PC With Intel® Dual Core Solution Quick Reference Guide Ed – 7 December 2012 Part No. E201742W7A0R...
-
Page 2: Getting Started
1.2 Packing List 1 x MPC-42W7 42" Full HD Fanless Multi Media Touch Panel PC With Intel® Dual Core Solution 1 x DVD-ROM contains the followings: ... -
Page 3: System Specifications
Switch 1 x Power switch 1 x mPCIe Expansion Slots SIM socket Others Mechanical Power Type a. AT/ATX Power Connector Type a. AC input Dimension 1045.4 x 663.4 x 86.4mm Weight Color Black Fanless Fanless MPC-42W7 Series Quick Reference Guide... - Page 4 MPC-42W7 Reliability EMI Test Class B CE FCC Safety Front side IP54 Dust and Rain Test 0°C ~ 40°C Operating Temperature Operating Humidity 0%~90% relative humidity, non-condensing Storage Temperature -20~70°C 4 MPC-42W7 Quick Reference Guide...
-
Page 5: System Overview
Function Note Power SWITCH Power-in connector Serial port DB-9 male connector KB/MS/LAN2 Keyboard-Mouse connector AC IN AC power-in connector HDMI HDMI connector Audio Audio connector USB connector RJ-45 Ethernet connector 1 LAN1 CF card slot MPC-42W7 Series Quick Reference Guide... -
Page 6: System Dimensions
MPC-42W7 1.5 System Dimensions (Unit: mm) 6 MPC-42W7 Quick Reference Guide... - Page 7 Quick Reference Guide 2. Hardware Configuration Note: If you need more information, please visit our website: http://www.avalue.com.tw MPC-42W7 Series Quick Reference Guide...
- Page 8 MPC-42W7 2.1 Installing HDD & MPCIE Step 1: Remove the back cover of your MPC-42W7 chassis. Step 2: Install your HDD into the HDD bracket by means of 4 screws. Step 3: Insert MPCIE cards into designated locations 8 MPC-42W7 Quick Reference Guide...
- Page 9 Quick Reference Guide Step 4: Place back the chassis and lock with 22 screws to finish. MPC-42W7 Series Quick Reference Guide...
