- Page 1 MPC-10W3 Fanless Intel® Atom™ N270 10”W Multifunctional Touch Panel PC with Intel® 945GSE + ICH7-M Chipset Quick Reference Guide Ed – March 2010 Copyright Notice Copyright © 2010-2011 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E201710W3A0R...
- Page 2 CORRECT THE INTERFERENCE AT HIS OWN EXPENSE. Copyright Notice Copyright © 2010-2011 Avalue Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
-
Page 3: Technical Support
Avalue Technology Inc. an Avalue Company Room 805, Building 9,No.99 Tianzhou Rd., 7 Marconi, Irvine, CA92618 Caohejing Development Area, Tel: +1-949-470-1888 Xuhui District, Shanghai Fax: +1-949-470-0971 Tel: +86-21-5169-3609 Information: BCMSales@bcmcom.com Fax:+86-21-5445-3266 Web: www.bcmcom.com Information: sales.china@avalue.com.cn Service: service@avalue.com.tw MPC-10W3 Quick Reference Guide... -
Page 4: Table Of Contents
1.1 Safety Precautions ....................5 1.2 Packing List.......................5 1.3 System Specifications ....................6 1.4 System Overview ......................8 1.4.1 Top View..........................8 1.4.2 Bottom View..........................8 1.5 System Dimensions ....................9 Hardware Configuration ..................10 2.1 Installing CF card and Memory ................11 4 MPC-10W3 Quick Reference Guide... -
Page 5: Getting Started
1.2 Packing List 1 x MPC-10W3 Panel PC 1 x Quick Reference Guide 1 x DVD-ROM contains the followings: — User’s Manual (this manual in PDF file) —... -
Page 6: System Specifications
LCD Size Resolution 1024 x 600 Pixel Pitch 0.21525mm (H) x 0.21525mm (V) 250cd/m² Luminance Contrast Ratio Viewing Angle 50(U), 60(D), 70(L), 70(R) Response Time 25ms Backlight LED Backlight Touch Type (Optional) 5-wires Resistive Touch Interface 6 MPC-10W3 Quick Reference Guide... - Page 7 0~40°C (32~104°F) Storage Temperature -20 to +75°C (-4~167°F) Relative Humidity 5 ~ 90% @ 40°C (104°F), relative humidity, non-condensing Size (L x W) 252.8 x 190 x 44.4mm Weight 1.22Kgs Mounting VESA 75 x 75mm, Wall/ Stand MPC-10W3 Quick Reference Guide...
-
Page 8: System Overview
LINE OUT 2 x USB 2.0 connector Dock USB RJ-45 Ethernet connector 1 LAN1 LAN2 RJ-45 Ethernet connector 2 (LAN2 is default, KB/MS is optional) (KB/MS) CRT connector DB-15 female connector DC IN DC Power-in connector 8 MPC-10W3 Quick Reference Guide... -
Page 9: System Dimensions
Quick Reference Guide 1.5 System Dimensions MPC-10W3 Quick Reference Guide... -
Page 10: Hardware Configuration
MPC-10W3 2. Hardware Configuration Note: If you need more information, please visit our website: http://www.avalue.com.tw 10 MPC-10W3 Quick Reference Guide... -
Page 11: Installing Cf Card And Memory
2.1 Installing CF card and Memory Step1. Unfasten 8 screws from the case then take off the top chassis. Step2. Insert the SODIMM into the memory socket. Step3. Place back the chassis with 8 screws locked. MPC-10W3 Quick Reference Guide 11... - Page 12 MPC-10W3 Step4. Unfasten the screws from the CF Socket cover. Step5. Insert the Compact Flash Card into the CF Socket 12 MPC-10W3 Quick Reference Guide...
