Model Two Owner's Manual

specifications

FM
Tuning Range (EU and US Tuning Capable) with RDS .................... 87.5-107.9MHz
Antenna Terminal ..................................................... External Antenna Connector
Usable Sensitivity ......................................................................................12.5 dBf
Selectivity .....................................................................................75 dB @ 400kHz
Signal to Noise Ratio ................................................ 62 dB (Stereo), 67 dB (Mono)
Harmonic Distortion @ 1 kHz ............................... 0.8% (stereo), 0.5% (monaural)
Separation ........................................................................................32 dB @ 1kHz
Frequency Response .........................................................................30-16,000 Hz
AM (EU and US Tuning Capable)
Tuning Range .................................................................................... 530-1710 kHz
Antenna Terminal ..................................................... External Antenna Connector
General
Dimensions (Radio Face Only) .........................................3.5"W x 1.5" H x 1.05" D
Dimensions (Radio Body) ............................................. 3.96"W x 1.98"H x 4.30"D
Power Requirements ............................................................................ 10.5-14.4V
Current Consumption (during operation) ................................................Max. 15A
Current Consumption (car off) ..................................................................<3.5 mA
Output Power (@ 14.4V @ 4 ohm @ 1% THD) ....... 25x4w RMS 45x4 Max Power
Output Impedance .................................................................................... 4-8ohm
Low Level Output (4 Channels)......................................................................2.85V
AUX 1 Input (Aux cable length, 8") ................................................ >300 mV / 6 kΩ
AUX 2 Input (Aux cable length, 8") ................................................ >300 mV / 6 kΩ
USB 1 Input (USB cable length, 40") ...................................5V (USB Female Input)
USB 2 Input (USB cable length, 40") ...................................5V (USB Female Input)
NOTE: All specifications are subject to change without notice.
Page 38
